ACT20P-2CI-2CO-12P-S
Product image
ACT20P-2CI-2CO-12P-S
Connection diagram
ACT20P-2CI-2CO-12P-S
Dimensioned drawing
ACT20P-2CI-2CO-12P-S
Similar to illustration
ACT20P-2CI-2CO-12P-S

ACT20P-2CI-2CO-12P-S

Analogue isolating amplifier, Input : 2 x 0(4) - 20 mA, Output : 0(4)-20 mA, Voltage supply also via CH20M rail bus, HART®

Produkt ID 1506210000
Im Konfigurator öffnen
Datenblatt herunterladen Engineering-support Produktdownloads
Tilbehør 2 Enkeltdele 1 Anvendte produkter 15
Approvals General ordering data Dimensions and weights Temperatures Probability of failure Environmental Product Compliance Input Output Output (analogue) General data Insulation coordination Data for Ex applications (ATEX) Connection data Part description Classifications

Approvals

Godkännanden
![](https://assets.dam.weidmueller.com/assets/api/98e12ea5-58f4-450a-9983-f439987b3951/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/0d1637a4-c7dd-4915-8bc8-4c9de8d8b393/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/4a92d911-d582-40e3-85fc-c9e9b159e140/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/2fb608f0-c73d-4515-a7a5-878046a505f4/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/52b59257-358c-4bc4-9ea4-df407cebf157/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/5855f480-81e6-48e1-aa53-1e87419df7ba/DAP_Master_ICON,w_80,q_80)
ROHS
Conform
UL File Number Search
[UL Website](https://database.ul.com/cgi-bin/XYV/cgifind/LISEXT/1FRAME/gfilenbr.html)
Certifikat-Nr. (cULus)
E469563
Certificat-nr (cULusEX)
E338066

General ordering data

Utförande
Analogue isolating amplifier, Input : 2 x 0(4) - 20 mA, Output : 0(4)-20 mA, Voltage supply also via CH20M rail bus, HART®
Art.nr.
1506210000
Typ
ACT20P-2CI-2CO-12P-S
GTIN (EAN)
4050118314625
Qty.
1 Styk

Dimensions and weights

Djup
113,7 mm
Depth (inches)
4,476 inch
Höjd
119,2 mm
Height (inches)
4,693 inch
Bredd
12,5 mm
Width (inches)
0,492 inch
Net weight
170 g

Temperatures

Lagertemperatur
-40 °C...85 °C
Drifttemperatur
-20 °C...60 °C
Humidity
5...95 %, no condensation

Probability of failure

SIL enligt IEC 61508
None

Environmental Product Compliance

RoHS-kompatibilitetsstatus
Compliant with exemption
RoHS-undantag (om tillämpligt/känt)
7a, 7cI
REACH SVHC
Lead 7439-92-1
SCIP
2f6dd957-421a-46db-a0c2-cf1609156924

Input

Antal ingångar
2
ingångssignal
HART signal® bidirectional
ingångsspänning
≤ 28 V DC
ingångsström
0...20 mA
4…20mA
Sensor
4- wire sensor (with own power supply)
Spänningsfall
≤ 1 V

Output

Antal utgångar
2
Lastmotstånd ström
<300 Ω
per channel
Typ
active
connected control must be passive
Utgångsström
0…20 mA (if input: 0…20 mA)
4…20 mA (if input: 4…20 mA)
HART® digital signal

Output (analogue)

Antal analoga utgångar
2

General data

Accuracy
<0.1 % of end value
Configuration
none
Current consumption
≤100 mA (24V power supply, 20mA output)
Mounting rail
TS 35
Nominal power consumption
2 VA
Operating altitude
≤ 2000 m
Protection degree
IP20
Step response time
≤ 0,5 ms
Supply voltage
20…30 V DC
via the system bus
Temperature coefficient
80 ppm/K
Type of signal forwarding according to HART®
unchanged

Insulation coordination

EMC-Normer
EN 61326-1
EN 61000-6-2
EN 61000-6-4
Galvanisk isolation
3-way isolator
between input ⁄ output ⁄ supply
Isolationsspänning
2 kV inputs / outputs / power supply
Nedsmutsningsgrad
2
Provspänning
0,3 kV
Stöthållspänning
4 kV (1.2/50 µs)
Överspänningskategori
III

Data for Ex applications (ATEX)

IECEx - gas labelling
Ex ec IIC T5 Gc
Marking
II 3 G Ex ec IIC T5 Gc

Connection data

Anslutningstyp
Screw connection
Åtdragningsmoment, min.
0,4 Nm
Tightening torque, max.
0,6 Nm
Clamping range, rated connection
2,5 mm²
Clamping range, min.
0,5 mm²
Clamping range, max.
2,5 mm²
Wire connection cross section AWG, min.
AWG 26
Wire connection cross section AWG, max.
AWG 12

Part description

Product description
The dual-channel, non-adjustable DC isolating amplifier ACT20P-2CI-2CO isolates analogue standard current source signals. An analogue input current signal is linearly converted into an analogue output current signal and is galvanically isolated. The power supply is galvanically isolated from the input and output (5-way isolation).

Properties
  • HART-compatible for 0.5 - 2.5 kHz
  • Operating status display on a front panel LED
  • Galvanic 5-way isolation between input, output and supply.


Classifications

ETIM 8.0
EC002653
ETIM 9.0
EC002653
ETIM 10.0
EC002653
ECLASS 14.0
27-21-01-20
ECLASS 15.0
27-21-01-20
