IE-AD-SP0-P-SPM-P-90

Single Pair Ethernet, Adapter, SPE socket acc. to IEC 63171-2, M8 socket male contact, T1-B, IEC 63171-2, IEC 63171-5, IP65 (in plugged condition)

Produkt ID 2814400000

Version	Single Pair Ethernet, Adapter, SPE socket acc. to IEC 63171-2, M8 socket male contact, T1-B, IEC 63171-2, IEC 63171-5, IP65 (in plugged condition)
Order No.	2814400000
Type	IE-AD-SP0-P-SPM-P-90
GTIN (EAN)	4064675299110
Qty.	10 Styk

Net weight

4,2 g

Operating temperature

-40 °C...85 °C

RoHS Compliance Status	Compliant with exemption
RoHS Exemption (if applicable/known)	6c
REACH SVHC	Lead 7439-92-1
SCIP	d1193a9e-dc7c-484a-ba48-176711eb392b

Dielectric strength, contact / contact	≥ 1000 V DC
Dielectric strength, contact / shield	2250 V DC
Insulation strength	≥ 500 MΩ
Operational voltage range	≤ 50 V AC ≤ 60 V DC
PoE / PoE+	PoDL acc. to IEEE 802.3bu / cg
Rated current	3.5 A at 0°C

Connector standard

IEC 63171-2
IEC 63171-5

Engineering Data	[CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_246636)
CADENAS eCATALOG	[CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2814400000)
Catalogues	[Catalogues in PDF-format](LINK/Catalog.html)

ROHS

Conform
