Ominaisuudet
| Version | with M23 outlet, 19-pole, M12, M23, 30 V, A-coded, LED: Yes, LED initiator: Yes, Wiring type: PNP |
| Order No. | 3023720000 |
| Type | SAI-06D-VP3V-5A-P12L-PNP |
| GTIN (EAN) | 4099986944725 |
| Qty. | 1 items |
| Height | 35,2 mm |
| Height (inches) | 1,386 inch |
| Width | 56 mm |
| Width (inches) | 2,205 inch |
| Length | 134 mm |
| Length (inches) | 5,276 inch |
| Net weight | 250 g |
| Operating temperature | -25 - 80°C |
| Distributor outlet |
with M23 outlet
19-pole |
| Tightening torque |
M12: 0.4 Nm
M23: 2.5 Nm |
| Connector standard | IEC 61076-2-010 |
| Rated voltage, min. | 10 V |
| Rated voltage, max. | 30 V |
| Max. current-carrying capacity per slot | 4 A |
| Total current | 10 A |
| Current per signal | 2 A |
| Electrical isolation available | No |
| Insulation strength | 109 Ω |
| Plug-in station coding | A-coded |
| Protection degree |
IP67
when screwed in |
| Number of poles | 5 |
| Number of contact sockets | 6 |
| Connection thread |
M12
M23 |
| Fire behaviour | V-0 |
| LED | Yes |
| LED initiator | Yes |
| LED colour for indicating operation | green |
| LED colour for I/O function | yellow |
| Material O-Ring | FKM, NBR |
| Housing main material | PBT |
| Material of distributor | Plastic |
| Housing colour | black |
| Contact material |
CuZn
CuSn |
| Contact surface | Gold-plated |
| Contact carrier material | PA |
| Number of poles | 5 |
| Suitable for cable carriers | No |
| Catalogues | [Calogues in PDF-format](https://www.weidmueller.com/int/service/technical_product_catalogues.jsp) |
| ETIM 6.0 | EC002585 |
| ETIM 7.0 | EC003558 |
| ETIM 8.0 | EC003558 |
| ETIM 9.0 | EC003558 |
| ETIM 10.0 | EC003558 |
| ECLASS 9.0 | 27-44-01-08 |
| ECLASS 9.1 | 27-44-01-08 |
| ECLASS 10.0 | 27-44-01-11 |
| ECLASS 11.0 | 27-44-01-11 |
| ECLASS 12.0 | 27-44-01-11 |
| ECLASS 13.0 | 27-44-01-11 |
| ECLASS 14.0 | 27-44-01-11 |
| ECLASS 15.0 | 27-44-01-11 |
| Approvals |  |
| ROHS | Conform |
