MULTIMETER C 2606 Item No. 9427370000
Digital clamp-on measuring device
Please note that any possible discounts or additional costs are not yet applied here. The definitive payment amounts will be shown in the cart.
Properties
| Version | Digital clamp-on measuring device |
| Order No. | 9427370000 |
| Type | MULTIMETER C 2606 |
| GTIN (EAN) | 4032248407019 |
| Qty. | 1 ST |
| Depth | 108 mm |
| Depth (inches) | 4.25196 inch |
| Height | 53 mm |
| Height (inches) | 2.08661 inch |
| Net weight | 888.2 g |
| Weight | 570 g |
| Width | 281 mm |
| Width (inches) | 11.06297 inch |
| REACH SVHC | Lead 7439-92-1 |
| Description of article | Digital clamp-on measuring device |
| AC voltage measuring range | 0.66 - 750 V |
| Battery type | 9V block battery |
| DC voltage measuring range | 0.66 - 1000 V |
| Display | digital |
| Frequency measurement | Yes |
| Frequency range, max. | 66 Hz |
| Frequency range, min. | 1 MHz |
| Measured capacitance value, max. | 6.6 mF |
| Measured capacitance value, min. | 6.6 nF |
| Measured current value, max. | 2000 A |
| Measuring range category | CAT III |
| Opening width of current-measuring clamp-on attachment | 57 mm |
| Resistance measuring range, max. | 66 MΩ |
| Resistance measuring range, min. | 660 Ω |
| Resolution of AC voltage | ± 0.5% |
| Resolution of DC voltage | ± 0.5% |
| Selection of measuring range | Manual |
| Tested and approved according to | VDE 0680, Part 5 |
| Type of current |
AC
DC |
| Working temperature, max. | 50 °C |
| Working temperature, min. | 0 °C |
| Product information | Min/max function only applies for the DC range. |
| Brochure/Catalogue | [CAT 6 TOOLS 15/16 EN](http://download.weidmueller.com/asset/download/file/39464) |
| Product Change Notification |
[Technical change DE](http://download.weidmueller.com/asset/download/file/153527)
[Technical change EN](http://download.weidmueller.com/asset/download/file/153528) |
| User Documentation | [Operating instructions](http://download.weidmueller.com/asset/download/file/153526) |
| ETIM 6.0 | EC000380 |
| ETIM 7.0 | EC000380 |
| eClass 9.0 | 27-20-03-12 |
| eClass 9.1 | 27-20-03-12 |
| eClass 10.0 | 27-20-03-12 |
| eClass 11.0 | 27200312 |
| Approvals |  |
| ROHS | Conform |
