PRO MAX 960W 48V 20A
PRO MAX 960W 48V 20A
Elektromos szimbólum
PRO MAX 960W 48V 20A
Visszaszabályozási görbe
PRO MAX 960W 48V 20A
Visszaszabályozási görbe

PRO MAX 960W 48V 20A

Power supply, switch-mode power supply unit, 48 V

Ürün No. 1478270000
Konfigüratörde aç
Veri sayfasını indir Engineering Support Product Downloads
Aksesuarlar 4 İlgili ürünler 12
Approvals General ordering data Dimensions and weights Temperatures Environmental Product Compliance Rated data UL Input Output General data EMC / shock / vibration Insulation coordination Electrical safety (applied standards) Connection data (input) Connection data (output) Signalling Classifications

Approvals

Jóváhagyások
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319222/-S800/-T1z1mm-S80)
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319228/-S800/-T1z1mm-S80)
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_322323/-S800/-T1z1mm-S80)
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319230/-S800/-T1z1mm-S80)
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319234/-S800/-T1z1mm-S80)
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319258/-S800/-T1z1mm-S80)
ROHS
Conform
UL File Number Search
[UL Website](https://database.ul.com/cgi-bin/XYV/cgifind/LISEXT/1FRAME/gfilenbr.html)
Certificate No. (cURus)
E255651
Tanúsítvány száma (cULus)
E258476
Tanúsítvány száma (EAC)
E470829

General ordering data

Változat
Power supply, switch-mode power supply unit, 48 V
Rendelési szám
1478270000
Típus
PRO MAX 960W 48V 20A
GTIN (EAN)
4050118286083
Qty.
1 adet

Dimensions and weights

Mélység
150 mm
Depth (inches)
5,905 inch
Magasság
130 mm
Height (inches)
5,118 inch
Szélesség
140 mm
Width (inches)
5,512 inch
Net weight
3 950 g

Temperatures

Tárolási hőmérséklet
-40 °C...85 °C
Üzemi hőmérséklet
-25 °C...70 °C
Humidity at operating temperature
5...95 %, no condensation
Start-up
≥ -40 °C

Environmental Product Compliance

RoHS megfelelőségi állapot
Compliant with exemption
RoHS alóli kivétel (ha van/ismert ilyen)
7a, 7cI
REACH SVHC
Lead 7439-92-1
SCIP
6d8cdf22-8230-4af8-86c8-3558c716666d

Rated data UL

Certificate No. (cURus)
E255651

Input

AC input voltage range
85…277 V AC
Current consumption in relation to the input voltage
  • Voltage type:
    AC
  • Input voltage:
    230 V
  • Input current:
    4,52 A
  • Voltage type:
    DC
  • Input voltage:
    120 V
  • Input current:
    10 A
DC input voltage range
80...370 V DC
Input fuse (internal)
Yes
Inrush current
max. 15 A
Märkingångsspänning
100...240 V AC
Nominal power consumption
1 021 VA
Surge protection
Varistor
Диапазон частот перем. тока
45…65 Hz
Рекомендуемый предохранитель
20 A, char. B circuit breaker
16 A, char. C, circuit breaker
결선 방식
Screw connection

Output

Connection system
Screw connection
Continuous output current @ UNominal
24 A @ 45°C, 15 A @ 70°C
Nominal output current for Unom
20 A @ 60 °C
Output power
960 W
Output voltage, max.
56 V
Output voltage, min.
30 V
Output voltage, note
(adjustable via potentiometer)
Parallel connection option
yes, max. 5
Protection against inverse voltage
Yes
Rated output voltage
48 V DC ± 1 %
Residual ripple, breaking spikes
<50 mVss @ UNenn, Full Load

General data

AC hiba áthidalási idő @ Inévl.
min. 20 ms
Felszerelési pozíció, telepítési figyelmeztetés
Horizontal on TS35 mounting rail. 50 mm of clearance at top &amp; bottom for air circ. Can mount side by side with no space in between.
Földszivárgóáram, max.
3,5 mA
Hatásfok
94%
Ház kiviteli változat
Metal, corrosion resistant
MTBF
  • According to Standard:
    SN 29500
  • Operating time (hours), min.:
    651 000 h
  • Ambient temperature:
    25 °C
  • Input voltage:
    230 V
  • Output power:
    960 W
  • Duty cycle:
    100 %
Pérdida de potencia, carga nominal
61,3 W
Short-circuit protection
Yes
Teljesítménytényező
  • Power factor typical:
    0.95
  • Input voltage:
    230 V
  • Ambient temperature:
    25 °C
  • Output power:
    960 W
Terheléstől érkező visszfeszültségek elleni védelem
58…65 V DC
Túlfeszültség kategória
III
Visszaszabályozás
> 60°C / 75% @ 70°C
Védelmi osztály
IP20
Ztráta výkonu, volnoběh
5 W
Állapotjelzés
LED red/green and relay (≥21.6 V DC LED green, relay on/ ≤20.6 LED red, relay off)
Áramkorlátozás
> 120% IN

EMC / shock / vibration

Interference immunity test acc. to
EN 55024
EN 55032
IEC61000-3-2,-3
IEC61000-4-2,-3,-4,-5,-6,-8,-11
Noise emission in accordance with EN55032
Class B
Shock resistance IEC 60068-2-27
30 g in all directions
Vibration resistance IEC 60068-2-6
2.3 g

Insulation coordination

Insulation voltage input / earth
3,5 kV
Insulation voltage output / earth
0,5 kV
Insulation voltage, input/output
4 kV
Pollution severity
2
Protection class
I, with PE connection
Surge voltage category
III

Electrical safety (applied standards)

Electrical machine equipment
Acc. to EN60204
Safety extra-low voltage
SELV acc. to IEC 60950-1
PELV according to EN 60204-1
Safety transformers for switch-mode power supplies
According to EN 61558-2-16

Connection data (input)

Conductor cross-section, AWG/kcmil , max.
10 AWG
Conductor cross-section, AWG/kcmil , min.
26 AWG
Conductor cross-section, flexible , min.
0,22 mm²
Conductor cross-section, rigid , max.
6 mm²
Conductor cross-section, rigid , min.
0,18 mm²
Connection system
Screw connection
Number of terminals
3 for L/N/PE
Screwdriver blade
0.8 x 4.0
PZ 1
Tightening torque, max.
0,6 Nm
Tightening torque, min.
0,5 Nm
Wire connection cross section, flexible (input), max.
4 mm²

Connection data (output)

Conductor cross-section, AWG/kcmil , max.
8 AWG
Conductor cross-section, AWG/kcmil , min.
22 AWG
Conductor cross-section, flexible , max.
16 mm²
Conductor cross-section, flexible , min.
0,5 mm²
Conductor cross-section, rigid , max.
16 mm²
Conductor cross-section, rigid , min.
0,5 mm²
Connection system
Screw connection
Number of terminals
8 (++,---,11,13,14)
Screwdriver blade
1.0 x 5.5
Tightening torque, max.
1,5 Nm
Tightening torque, min.
1,2 Nm

Signalling

Carico di contatto (contatto NA)
max. 30 V DC / 1 A
Floating contact
Yes
Status indication
LED red/green and relay (≥21.6 V DC LED green, relay on/ ≤20.6 LED red, relay off)

Classifications

ETIM 8.0
EC002540
ETIM 9.0
EC002540
ETIM 10.0
EC002540
ECLASS 14.0
27-04-07-01
ECLASS 15.0
27-04-07-01
