Egenskaber
| Version | Photovoltaics, Assembled enclosure, Communication module, 230 V AC, Surge protection I, Current monitoring, Monitoring components, Voltage monitoring, Limit value monitoring, Communication Box, RJ45 |
| Order No. | 8000111622 |
| Type | PV CPCI23TXUXDXAXWXRXWW |
| GTIN (EAN) | 4099986678897 |
| Qty. | 1 Styk |
| Depth | 180 mm |
| Depth (inches) | 7,087 inch |
| Height | 270 mm |
| Height (inches) | 10,63 inch |
| Width | 360 mm |
| Width (inches) | 14,173 inch |
| Net weight | 4.000 g |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c, 7a, 7cI |
| REACH SVHC | Lead 7439-92-1 |
| Earthing | Directly at the VPU |
| Rated voltage | 230 V |
| Surge protection AC side | PU I 1+1 LCF 280V/12,5kA, without auxiliary contact |
| Surge protection WIA RS485 side (string monitoring) | No |
| Number of conduit inlets | 3 |
| Number of inputs | 1 |
| Monitoring function |
Industrial PC
Industrial Ethernet router with 4G and RJ45 ports Connection between field devices to SCADA through RS-485 |
| Voltage monitoring | Yes |
| Protection degree | IP65 |
| Type of mounting |
Wall mounting
Indoors only |
| Standards |
IEC 61439-2 ed 3.0
EN 61439-2:2020 |
| Time interval | 5 years |
| Approval/Certificate/Document of Conformity | [Declaration of of conformity utility communication boxes](https://mdcop.weidmueller.com/mediadelivery/asset/900_318636) |
| Engineering Data | [Thermal Report](https://mdcop.weidmueller.com/mediadelivery/asset/900_317240) |
| Technical Documentation | [Mechanical Drawing](https://mdcop.weidmueller.com/mediadelivery/asset/900_317239) |
| User Documentation | [PV Communication Box User Manual](https://mdcop.weidmueller.com/mediadelivery/asset/900_257190) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002928 |
| ETIM 7.0 | EC002928 |
| ETIM 8.0 | EC003857 |
| ETIM 9.0 | EC003857 |
| ECLASS 9.0 | 22-57-92-03 |
| ECLASS 9.1 | 22-57-02-90 |
| ECLASS 10.0 | 22-57-02-90 |
| ECLASS 11.0 | 22-57-02-92 |
| ECLASS 12.0 | 22-57-02-92 |
| ECLASS 13.0 | 22-57-02-92 |
| ECLASS 14.0 | 22-57-02-92 |
| Approvals |  |
| ROHS | Conform |
