Ominaisuudet
| Version | Pneumatic contact, Contact with valve: Yes |
| Order No. | 2637400000 |
| Type | HDC MPN 6.0 SOF |
| GTIN (EAN) | 4050118654547 |
| Qty. | 10 items |
| Net weight | 1,438 g |
| Limit temperature | -40 °C ... 80 °C |
| REACH SVHC | / |
| RoHS Compliance Status | Compliant without exemption |
| Type | Female |
| Operating pressure | ≤8 bar |
| Inner hose diameter | 6 mm |
| Contact with valve | Yes |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_96074) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2637400000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002943 |
| ETIM 7.0 | EC002943 |
| ETIM 8.0 | EC002943 |
| ETIM 9.0 | EC002943 |
| ECLASS 9.0 | 27-44-02-92 |
| ECLASS 9.1 | 27-44-02-92 |
| ECLASS 10.0 | 27-44-02-92 |
| ECLASS 11.0 | 27-44-02-92 |
| ECLASS 12.0 | 27-44-02-92 |
| ECLASS 13.0 | 27-44-02-92 |
| ECLASS 14.0 | 27-44-02-92 |
| ROHS | Conform |
