Ominaisuudet
| Version | Adapter, MICRO-Interface, IEC 60603/DIN41612 plug-in connectors, Screw connection |
| Order No. | 8800230000 |
| Type | MI-A-PSM24VDC |
| GTIN (EAN) | 4032248497171 |
| Qty. | 10 items |
| Depth | 6 mm |
| Depth (inches) | 0,236 inch |
| Height | 98 mm |
| Height (inches) | 3,858 inch |
| Width | 88 mm |
| Width (inches) | 3,465 inch |
| Net weight | 32 g |
| Storage temperature | -20...85 °C |
| Operating temperature | 0...50 °C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Voltage supply | max. 30 V AC/DC |
| Operating voltage | 30 V UC |
| Max. current per channel | 0,5 A |
| Total operating current | 2 A |
| According to | DIN EN 50178 |
| Rated insulation voltage | < 50 V AC |
| Surge voltage category | III |
| Pollution severity level | 2 |
| Insulation test voltage AC | 0,35 kV |
| Type of connection | Screw connection |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002584 |
| ETIM 7.0 | EC002584 |
| ETIM 8.0 | EC002584 |
| ETIM 9.0 | EC002584 |
| ECLASS 9.0 | 27-33-02-92 |
| ECLASS 9.1 | 27-24-22-92 |
| ECLASS 10.0 | 27-33-02-92 |
| ECLASS 11.0 | 27-33-02-92 |
| ECLASS 12.0 | 27-33-02-92 |
| ECLASS 13.0 | 27-33-02-92 |
| ECLASS 14.0 | 27-33-02-92 |
| ROHS | Conform |
