Ominaisuudet
| Version | Cross-connector (terminal), Plugged, beige, 57 A, Number of poles: 2, Pitch in mm (P): 10.00, Insulated: Yes, Width: 20 mm |
| Order No. | 1669280000 |
| Type | QS 2/10/4 O.STGF |
| GTIN (EAN) | 4008190428341 |
| Qty. | 20 items |
| Depth | 34,5 mm |
| Depth (inches) | 1,358 inch |
| Height | 12 mm |
| Height (inches) | 0,472 inch |
| Width | 20 mm |
| Width (inches) | 0,787 inch |
| Net weight | 5,05 g |
| Storage temperature | -25 °C...55 °C |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 20993c56-321a-4ec1-8646-b7d545a927f2 |
| Material | PA 66 |
| Colour | beige |
| Version | Cross-connector |
| Explosion-tested version | No |
| Type of fixing | Plugged |
| Type of mounting | Plugged |
| Rated current, multi-pole | 57 A |
| Type | Cross-connector |
| Pitch in mm (P) | 10 mm |
| Number of poles | 2 |
| Rated current | 57 A |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_74514) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1669280000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1669280000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000489 |
| ETIM 7.0 | EC000489 |
| ETIM 8.0 | EC000489 |
| ETIM 9.0 | EC000489 |
| ECLASS 9.0 | 27-14-11-40 |
| ECLASS 9.1 | 27-14-11-40 |
| ECLASS 10.0 | 27-14-11-40 |
| ECLASS 11.0 | 27-14-11-40 |
| ECLASS 12.0 | 27-14-11-40 |
| ECLASS 13.0 | 27-25-03-03 |
| ECLASS 14.0 | 27-25-03-03 |
| ROHS | Conform |
