Ominaisuudet
| Order No. | 2992970000 |
| Type | RC F P3 C SP |
| GTIN (EAN) | 4099986872042 |
| Diameter | 20 mm |
| Net weight | 0.02 g |
| Operating temperature | -40 °C...60 °C |
| RoHS Compliance Status | Compliant without exemption |
| RoHS Exemption (if applicable/known) | 6c |
| REACH SVHC | No SVHC above 0.1 wt% |
| Cable diameter, max. | 9 mm |
| Cable diameter, min. | 7.5 mm |
| Coding | none |
| Conductor cross-section, max. | 1.5 mm² |
| Conductor cross-section, min. | 0.25 mm² |
| Connection cross-section, max. | 4 mm² |
| Connection cross-section, min. | 0.5 mm² |
| Contact material | Brass |
| Contact surface | Brass |
| Housing main material | PA 66 |
| Number of poles | 3 |
| Protection degree | IP68 |
| Rated current | 17.5 A |
| Rated voltage | 500 V |
| Shield connection | No |
| Type of connection |
PUSH IN
Lever clamp |
| Housing main material | PA 66 |
| Number of poles | 3 |
| Type of connection |
PUSH IN
Lever clamp |
| Cable diameter, max. | 9 mm |
| Cable diameter, min. | 7.5 mm |
| Coding | none |
| Conductor cross-section, max. | 1.5 mm² |
| Conductor cross-section, min. | 0.25 mm² |
| Contact material | Brass |
| Contact surface | Brass |
| Max. dismantling length | 28 mm |
| Min. dismantling length | 25 mm |
| Protection degree | IP68 |
| Rated current | 17.5 A |
| Rated impulse withstand voltage | 2.5 kV |
| Rated voltage | 500 V |
| Shield connection | No |
| Stripping length | 6 mm |
| UL 94 flammability rating | V-0 |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002635 |
| ETIM 7.0 | EC002635 |
| ETIM 8.0 | EC002635 |
| ETIM 9.0 | EC002635 |
| ECLASS 9.0 | 27-44-01-02 |
| ECLASS 9.1 | 27-44-01-03 |
| ECLASS 10.0 | 27-44-01-02 |
| ECLASS 11.0 | 27-44-01-02 |
| ECLASS 12.0 | 27-44-01-16 |
| ECLASS 13.0 | 27-44-01-02 |
| ECLASS 14.0 | 27-44-01-16 |
| ROHS | Conform |
