SAI-06Z-VPUT-4A-M08L-PNP

Sensor-actuator passive distributor, M8, LED: Yes, Number of poles: 4, Number of contact sockets: 6

Tuotteen tunnus 2819060000
Lataa tietosivu Engineering Support Product Downloads
Lisävarusteet 3 Samankaltaiset tuotteet 16
Approvals General ordering data Dimensions and weights Temperatures Environmental Product Compliance Connection data Electrical data Allmänna tekniska data Material data Technical data cable Classifications

Approvals

Omologazioni
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319222/-S800/-T1z1mm-S80)
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319228/-S800/-T1z1mm-S80)
ROHS
Conform
UL File Number Search
[UL Website](https://database.ul.com/cgi-bin/XYV/cgifind/LISEXT/1FRAME/gfilenbr.html)
Certificate no. (cULus)
E141197

General ordering data

Versione
Sensor-actuator passive distributor, M8, LED: Yes, Number of poles: 4, Number of contact sockets: 6
N. d’ordine
2819060000
유형
SAI-06Z-VPUT-4A-M08L-PNP
GTIN (EAN)
4064675330288
CPZ
1 items

Dimensions and weights

Net weight
10 g

Temperatures

Рабочая температура
-25 - 80°C

Environmental Product Compliance

Состояние соответствия RoHS
Compliant without exemption
REACH SVHC
No SVHC above 0.1 wt%

Connection data

Диапазон зажима, мин.
0,08 mm²
1,5 mm²
Elosztó kimenet
Hood distributor lower part
Type of connection
PUSH IN

Electrical data

Rated voltage, min.
15 V
Rated voltage, max.
30 V
Max. current-carrying capacity per slot
4 A
Total current
6 A
Courant par signal
2 A
Avec isolation de potentiel
No

Allmänna tekniska data

Degré de protection
IP67
Nombre de pôles
4
Nombre de contacts femelles
6
Rosca de conexión
M8
Degré de pollution
3
Viselkedés tűzben
V-0
LED
Yes
LED iniciátor
Yes
Couleur de LED pour indicateur de fonctionnement
green
Couleur de LED pour indicateur E/S
yellow

Material data

Material junta tórica
FKM
Housing main material
PBT
Material of distributor
Plastic
Color de carcasa
black (similar to RAL 9005)
Matériau du joint du capot
FKM
Csavaros aljzat
CuZn, никелирование
Материал контакта
CuZn
Contact surface
Gold-plated
Contact carrier material
PBT (UL 94 V0)

Technical data cable

Pólusszám
4
A következő kábeltartókhoz:
No

Classifications

ETIM 8.0
EC003558
ETIM 9.0
EC003558
ETIM 10.0
EC003558
ECLASS 14.0
27-44-01-11
ECLASS 15.0
27-44-01-11
