Ominaisuudet
| Version | Marking systems, Thermotransfer printer, Thermal transfer, 300 DPI, MultiMark, Shrink-fit sleeves, Label reel |
| Order No. | 2599440000 |
| Type | THM MULTIMARK PLUS |
| GTIN (EAN) | 4050118626360 |
| Qty. | 1 items |
| Depth | 274 mm |
| Depth (inches) | 10,787 inch |
| Height | 446 mm |
| Height (inches) | 17,559 inch |
| Width | 242 mm |
| Width (inches) | 9,528 inch |
| Net weight | 10 000 g |
| RoHS Compliance Status | Compliant |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 7d9d08e1-8ede-49b5-a637-5ea27a383bef |
| Included in delivery |
THM MultiMark
USB cable Ink ribbon core Print roller Pressure roller Manual W-LAN stick Mains cable Euro plug US plug UK plug Printer driver Software M-Print® PRO RIBBON MM-TB 25/360 SW ink ribbon RIBBON MM 110/360 SW ink ribbon |
| Interface |
USB 2.0
Ethernet Wi-Fi |
| Marker type |
MultiMark
Shrink-fit sleeves Label reel |
| Operating system |
Windows 7
Windows 8 Windows 8.1 Windows 10 |
| Operation with rechargeable batteries | No |
| Print resolution, max. | 300 DPI |
| Printing method | Thermal transfer |
| Printing speed | max. 300 mm/s |
| Software | M-Print® PRO |
| System requirements | PC with operating system Windows 7, 8 or 10 |
| Voltage supply | 100…240 V AC |
| Approval/Certificate/Document of Conformity |
[China RoHS Declaration](https://mdcop.weidmueller.com/mediadelivery/asset/900_167277)
[Declaration of Conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_85820) |
| User Documentation | [MANUAL THM MULTIMARK PLUS](https://mdcop.weidmueller.com/mediadelivery/asset/900_89170) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000610 |
| ETIM 7.0 | EC000610 |
| ETIM 8.0 | EC000610 |
| ETIM 9.0 | EC000610 |
| ECLASS 9.0 | 24-32-11-90 |
| ECLASS 9.1 | 24-32-11-02 |
| ECLASS 10.0 | 24-32-11-90 |
| ECLASS 11.0 | 24-32-11-90 |
| ECLASS 12.0 | 24-32-11-90 |
| ECLASS 13.0 | 24-32-11-90 |
| ECLASS 14.0 | 24-32-11-90 |
| Approvals |  |
| ROHS | Conform |
