Ominaisuudet
| Order No. | 2995040000 |
| Type | WBC-P-8BK-70 |
| GTIN (EAN) | 4099986882218 |
| Qty. | 5 items |
| Net weight | 45,3 g |
| Continuous operating temp., min. | −40 °C |
| Continuous operating temp., max. | 125 °C |
| Limit temperature | -40 °C ... 125 °C |
| REACH SVHC | / |
| RoHS Compliance Status | Compliant |
| Approvals | UL 4128 |
| Colour | black |
| Conductor cross-section, max. | 70 mm² |
| Contact diameter, male Ø | 8 mm |
| Material | PA 66 |
| Outer cable diameter, max. | 15,4 mm |
| Outer cable diameter, min. | 14,7 mm |
| Surface finish | silver |
| Type | Female |
| Type of connection | Crimp connection |
| Plugging cycles | ≥ 100 |
| Protection degree | IP67 plugged |
| Rated current | 250 A |
| Rated voltage | 1 500 V |
| UL 94 flammability rating | V-0 |
| Volume resistance | ≥ 5000 MΩ |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 7.0 | EC001121 |
| ETIM 8.0 | EC001121 |
| ETIM 9.0 | EC001121 |
| ECLASS 10.0 | 27-44-03-12 |
| ECLASS 11.0 | 27-44-03-12 |
| ECLASS 12.0 | 27-44-03-12 |
| ECLASS 13.0 | 27-44-03-12 |
| ECLASS 14.0 | 27-44-03-12 |
| ROHS | Conform |
