Eigenschappen
| Version | Miniature fuse, quick-acting, 5 A, Blade fuse type C |
| Order No. | 1278750000 |
| Type | ETA 1170 21 5A |
| GTIN (EAN) | 4050118091274 |
| Qty. | 5 items |
| Depth | 51,6 mm |
| Depth (inches) | 2,031 inch |
| Height | 22 mm |
| Height (inches) | 0,866 inch |
| Width | 9,8 mm |
| Width (inches) | 0,386 inch |
| Net weight | 9,6 g |
| Continuous operating temp., min. | -50 °C |
| Continuous operating temp., max. | 120 °C |
| RoHS Compliance Status | Compliant |
| REACH SVHC | No SVHC above 0.1 wt% |
| Colour | black |
| Version | Fuse cartridge |
| Installation advice | Direct mounting |
| Type of mounting | Plugged |
| Cartridge fuse | Blade fuse type C |
| Characteristics | quick-acting |
| Colour | black |
| Current | 5 A |
| Version | Fuse cartridge |
| Installation advice | Direct mounting |
| Rated voltage | 28 V |
| Rated current | 5 A |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1278750000) |
| User Documentation | [StorageConditionsTerminalBlocks](https://mdcop.weidmueller.com/mediadelivery/asset/900_87149) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000035 |
| ETIM 7.0 | EC000035 |
| ETIM 8.0 | EC002704 |
| ETIM 9.0 | EC002704 |
| ECLASS 9.0 | 27-14-20-01 |
| ECLASS 9.1 | 27-14-20-01 |
| ECLASS 10.0 | 27-14-20-01 |
| ECLASS 11.0 | 27-14-20-01 |
| ECLASS 12.0 | 27-14-20-01 |
| ECLASS 13.0 | 27-14-20-01 |
| ECLASS 14.0 | 27-14-20-01 |
| ROHS | Conform |
Is accessoire van
-
Product ID:1058520000VPE:10 items
Z-series, Fuse terminal, Rated cross-section: 6 mm², Tension-clamp connection, black, Direct mounting
Terminal BlocksUniversal rangeTension clamp technologyZ-SeriesStandardFuse terminal blocks1-tier6 mm²Automotive fuse
