Version | FrontCom, Double frame, Metal cover, Control knob locking, NEMA 4X |
Order No. | 2669640000 |
Type | IE-FC-DFM-KNOB-4X |
GTIN (EAN) | 4050118800531 |
Qty. | 1 items |
Depth | 27,5 mm |
Depth (inches) | 1,083 inch |
Height | 134 mm |
Height (inches) | 5,276 inch |
Width | 132 mm |
Width (inches) | 5,197 inch |
Wall thickness, min. | 1 mm |
Wall thickness, max. | 5 mm |
Net weight | 824,97 g |
Operating temperature | -40 °C...70 °C |
RoHS Compliance Status | Compliant without exemption |
REACH SVHC | No SVHC above 0.1 wt% |
Material cover |
Zinc diecast
powder-coated |
Material frame |
Zinc diecast
powder-coated |
Product type |
Double frame
Metal cover Control knob locking NEMA 4X |
Protection class (UL) | Type 4X |
Protection degree |
IP65
in closed state |
Certificate No. (CSA) | 2000039-80039714 |
Certificate No. (cURus) | E223801 |
Certificate No. (DNV) | TAA000022B |
Engineering Data | |
Eplan Data Portal | |
CADENAS eCATALOG | |
User Documentation | |
Catalogues |
ETIM 6.0 | EC001031 |
ETIM 7.0 | EC001031 |
ETIM 8.0 | EC001031 |
ETIM 9.0 | EC001031 |
ECLASS 9.0 | 27-18-27-02 |
ECLASS 9.1 | 27-18-27-90 |
ECLASS 10.0 | 27-18-27-02 |
ECLASS 11.0 | 27-18-27-02 |
ECLASS 12.0 | 27-18-28-92 |
ECLASS 13.0 | 27-18-28-92 |
ECLASS 14.0 | 27-18-28-92 |
Approvals | ![]() ![]() ![]() |
ROHS | Conform |
UL File Number Search | |
Certificate No. (cURus) | E223801 |
-
