Eigenschappen
| Version | Power connector, Plug, PROFINET, Set of connectors |
| Order No. | 2465440000 |
| Type | IE-PS-VAPM-5P-2.5 |
| GTIN (EAN) | 4050118522136 |
| Qty. | 1 items |
| Height | 36,2 mm |
| Height (inches) | 1,425 inch |
| Width | 26,8 mm |
| Width (inches) | 1,055 inch |
| Length | 85,4 mm |
| Length (inches) | 3,362 inch |
| Net weight | 96 g |
| Operating temperature | -40 °C...70 °C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Cable sealing material | EPDM |
| Colour | Silver grey |
| Connection 1 | PushPull Power |
| Connection 2 | Tension clamp |
| Contact material | Cu-alloy |
| Contact surface | Gold over nickel |
| Housing main material |
Zinc diecast
nickel-plated |
| Number of poles | 5 |
| Plugging cycles | ≥ 100 |
| Pollution severity | 2 |
| Protection degree |
IP65
IP67 |
| Sealing material | NBR |
| Sheath diameter, max. | 13 mm |
| Sheath diameter, min. | 8 mm |
| Shielding | unshielded |
| Type of interlock | Push Pull |
| UL 94 flammability rating | V-2 |
| Wire connection cross section, finely stranded, max. | 2,5 mm² |
| Wire connection cross section, finely stranded, min. | 0,75 mm² |
| Current-carrying capacity at 50 °C | 16 A |
| Operating voltage | 24 V |
| Certificate No. (UR) | E92202 |
| Connector standard |
in accordance with PROFINET specification
IEC 61076-3-126 |
| Connector standard |
in accordance with PROFINET specification
IEC 61076-3-126 |
| Product information | For cables with outer diameter 6-8 mm, order additional reducing seal. |
| Approval/Certificate/Document of Conformity | [PROFINET Manufacturer's Declaration](https://mdcop.weidmueller.com/mediadelivery/asset/900_67339) |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_42774) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2465440000) |
| Product Change Notification |
[20201001 Technische Änderungen zum Push Pull Power Steckverbinder](https://mdcop.weidmueller.com/mediadelivery/asset/900_178561)
[20201001 Technical change to Push Pull Power connector](https://mdcop.weidmueller.com/mediadelivery/asset/900_178562) [Technische Änderung der Bedruckung auf PushPull Power Kontakteinsätzen](https://mdcop.weidmueller.com/mediadelivery/asset/900_274248) [Technical change to printing on PushPull Power contact inserts](https://mdcop.weidmueller.com/mediadelivery/asset/900_274249) |
| User Documentation |
[Designation key / Type key](https://mdcop.weidmueller.com/mediadelivery/asset/900_90842)
[Manual](https://mdcop.weidmueller.com/mediadelivery/asset/900_91108) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC001121 |
| ETIM 7.0 | EC001121 |
| ETIM 8.0 | EC001121 |
| ETIM 9.0 | EC001121 |
| ECLASS 9.0 | 27-44-03-90 |
| ECLASS 9.1 | 27-44-03-90 |
| ECLASS 10.0 | 27-44-03-90 |
| ECLASS 11.0 | 27-44-03-90 |
| ECLASS 12.0 | 27-44-03-90 |
| ECLASS 13.0 | 27-44-03-90 |
| ECLASS 14.0 | 27-44-03-90 |
| Approvals |  |
| ROHS | Conform |
| UL File Number Search | [UL Website](LINK/UL_search.html) |
| Certificate No. (UR) | E92202 |
