Eigenschappen
| Version | Y connector |
| Order No. | 2616420000 |
| Type | SAI-H3-M12-T |
| GTIN (EAN) | 4050118621389 |
| Qty. | 1 items |
| Net weight | 103 g |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 4060c755-8d0b-4d43-bdb3-4ffabe9d7497 |
| Group outlet - plug-in connector | M12 pin |
| Single outlet 1 - plug-in connector | M12 socket |
| Single outlet 2 - plug-in connector | M12 socket |
| Single outlet 3 - plug-in connector | M12 socket |
| Cable glands | M 12 |
| Coding | T-coded |
| Contact surface | Gold-plated |
| Housing main material | TPU |
| Insulation strength | ≥ 100 MΩ |
| Number of poles | 4 |
| Pollution severity | 3 |
| Protection degree | IP67 |
| Rated current | 12 A |
| Shield connection | No |
| Temperature range of housing | -30…+90 °C |
| Connector standard | IEC 61076-2-111 |
| Cable glands | M 12 |
| Coding | T-coded |
| Conductor O.D. | - |
| Contact surface | Gold-plated |
| Housing main material | TPU |
| Insulation strength | ≥ 100 MΩ |
| Number of poles | 4 |
| Pollution severity | 3 |
| Protection degree | IP67 |
| Rated current | 12 A |
| Rated voltage | 63 V DC |
| Shield connection | No |
| Temperature range of housing | -30…+90 °C |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_205582) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2616420000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002925 |
| ETIM 7.0 | EC002925 |
| ETIM 8.0 | EC002925 |
| ETIM 9.0 | EC002925 |
| ECLASS 9.0 | 27-44-01-06 |
| ECLASS 9.1 | 27-44-01-06 |
| ECLASS 10.0 | 27-44-01-06 |
| ECLASS 11.0 | 27-44-01-06 |
| ECLASS 12.0 | 27-44-01-06 |
| ECLASS 13.0 | 27-44-01-06 |
| ECLASS 14.0 | 27-44-01-06 |
| Approvals |    |
| ROHS | Conform |
| UL File Number Search | [UL Website](LINK/UL_search.html) |
| Certificate no. (cULus) | E310075 |
