Eigenschappen
| Order No. | 3072570000 |
| Type | WBC-CH-10RE-BK-95-0032 |
| GTIN (EAN) | 4099987074742 |
| Qty. | 5 items |
| Length | 324 mm |
| Length (inches) | 12,756 inch |
| Net weight | 500 g |
| Continuous operating temp., min. | -40 °C |
| Continuous operating temp., max. | 125 °C |
| Colour |
black
orange |
| Conductor cross-section, max. | 95 mm² |
| Contact diameter, male Ø | 6 mm |
| Material | PA 66 |
| Outer cable diameter, max. | 6 mm |
| Surface finish | silver |
| Type | Female |
| Type of connection | Crimp connection |
| Length | 324 mm |
| Plugging cycles | ≥ 100 |
| Protection degree | IP67 plugged |
| Rated current | 350 A |
| Rated voltage | 1.500 V |
| UL 94 flammability rating | V-0 |
| Catalogues | [Calogues in PDF-format](https://www.weidmueller.com/int/service/technical_product_catalogues.jsp) |
| ETIM 7.0 | EC001121 |
| ETIM 8.0 | EC001121 |
| ETIM 9.0 | EC001121 |
| ETIM 10.0 | EC001121 |
| ECLASS 10.0 | 27-44-03-12 |
| ECLASS 11.0 | 27-44-03-12 |
| ECLASS 12.0 | 27-44-03-12 |
| ECLASS 13.0 | 27-44-03-12 |
| ECLASS 14.0 | 27-44-03-12 |
| ECLASS 15.0 | 27-44-03-12 |
| ROHS | Conform |
