Pneumatic module, Number of poles: 3, Hose connection (pneumatic), pneumatic, Required plug-in slots: 1

Ürün No. 2637340000
Veri sayfasını indir Mühendislik desteği Ürün İndirmleri
Aksesuarlar 9 aksesuarıdır 9 İlgili ürünler 2
승인 Datos generales para pedido Dimensions and weights Temperatures Conformidad medioambiental del producto General data Pneumatic module Version Besorolások

승인

ROHS
준수

Datos generales para pedido

Version
Pneumatic module, Number of poles: 3, Hose connection (pneumatic), pneumatic, Required plug-in slots: 1
Order No.
2637340000
Type
HDC MPN 3
GTIN (EAN)
4050118765823
Qty.
1 items

Dimensions and weights

Net weight
6,603 g

Temperatures

Limit temperature
-40 °C ... 80 °C

Conformidad medioambiental del producto

RoHS Compliance Status
Conforme sin exención
REACH SVHC
Potassium perfluorobutane sulfonate 29420-49-3
SCIP
1609748e-c278-4c9b-b3d1-e6215d2988cd

General data

Basic material
Polycarbonate, glass fibre reinforced
Number of poles
3
Plugging cycles
≥ 500
Required plug-in slots
1
Series
ModuPlug
Type
pneumatic
UL 94 flammability rating
V-0

Pneumatic module

Module operating pressure
8 bar
Inner hose diameter, min.
1,6 mm
Inner hose diameter, max.
4 mm

Version

Conductor cross-section, max.
0 mm²
Conductor cross-section, min.
0 mm²
Type of connection
Hose connection (pneumatic)

Besorolások

ETIM 8.0
EC000438
ETIM 9.0
EC000438
ETIM 10.0
EC000438
ECLASS 14.0
27-44-02-20
ECLASS 15.0
27-44-02-20
