Özellikler
| Version | Photovoltaics, Cartridge fuse, 1500 V, 22x58, gPV, 35 A |
| Order No. | 2865970000 |
| Type | FUSE WSFL 22X58 35A 1K5V GPV |
| GTIN (EAN) | 4064675602415 |
| Qty. | 10 adet |
| Height | 58 mm |
| Height (inches) | 2,283 inch |
| Width | 22 mm |
| Width (inches) | 0,866 inch |
| Net weight | 50 g |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Fuse-link standard |
IEC 60269-6
gPV (EN 60269-6) |
| Current | 35 A |
| Rated DC voltage | 1.500 V |
| Power dissapation, max. | 9,8 W |
| Engineering Data | [FUSE WSFL 22X58 40A 1K5V GPV](https://mdcop.weidmueller.com/mediadelivery/asset/900_253747) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 7.0 | EC002704 |
| ETIM 8.0 | EC002704 |
| ETIM 9.0 | EC002704 |
| ECLASS 11.0 | 27-14-20-02 |
| ECLASS 12.0 | 27-14-20-02 |
| ECLASS 13.0 | 27-14-20-02 |
| ECLASS 14.0 | 27-14-20-02 |
| ROHS | Conform |
aksesuarıdır
-
Ürün No.:4000003740Ambalaj birimi:6 adet
Photovoltaics, Fuse holder, 1500 V, 22x58, Without LED
PhotovoltaicsAccessoriesComponentsFuse Holders22x58 mm
