Özellikler
| Version | PCB connection element M12, Solder connection, Cat.5 (ISO/IEC 11801), IP65 in acc. with DIN EN 60529 |
| Order No. | 1393470000 |
| Type | IE-M12-PCBCE-PANEL-A |
| GTIN (EAN) | 4050118194241 |
| Qty. | 10 adet |
| Net weight | 12,2 g |
| Operating temperature | -40 °C...85 °C |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 9229992a-00b9-4096-8962-200a7f33e289 |
| Coding | D-coded |
| Number of poles | 4 |
| Protection degree | IP65 in acc. with DIN EN 60529 |
| Housing main material |
CuZn
Polyamide nickel-plated |
| Connection thread | M12 |
| Number of poles | 4 |
| Connection 1 | M12 |
| Connection 2 | Solder connection |
| Description of article | Connecting element, clip-on |
| Configuration | Reflow compatible |
| Housing main material |
CuZn
Polyamide nickel-plated |
| Category | Cat.5 (ISO/IEC 11801) |
| Connection thread | M12 |
| Protection degree | IP65 in acc. with DIN EN 60529 |
| Approval/Certificate/Document of Conformity | [PROFINET Manufacturer's Declaration](https://mdcop.weidmueller.com/mediadelivery/asset/900_67339) |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_96161) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1393470000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC003568 |
| ETIM 8.0 | EC003568 |
| ETIM 9.0 | EC003568 |
| ECLASS 9.0 | 27-44-03-09 |
| ECLASS 9.1 | 27-44-03-09 |
| ECLASS 10.0 | 27-44-03-09 |
| ECLASS 11.0 | 27-44-01-10 |
| ECLASS 12.0 | 27-44-01-10 |
| ECLASS 13.0 | 27-44-01-10 |
| ECLASS 14.0 | 27-44-01-10 |
| ROHS | Conform |
