Özellikler
| Version | Built-in plugs, M8 PCB insert, IP67 with housing, SMD solder connection, 180°, Number of poles: 2 |
| Order No. | 2795110000 |
| Type | IE-PCB-SPM-P-180-SMD |
| GTIN (EAN) | 4064675119166 |
| Qty. | 100 adet |
| Depth | 14,5 mm |
| Depth (inches) | 0,571 inch |
| Height | 22,1 mm |
| Height (inches) | 0,87 inch |
| Width | 10,1 mm |
| Width (inches) | 0,398 inch |
| Net weight | 5,14 g |
| Operating temperature | -40 °C...85 °C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Category | T1-B |
| Mounting onto the PCB | SMD solder connection |
| Number of poles | 2 |
| Outgoing elbow | 180° |
| Performance-Category | T1-B |
| Plugging cycles | ≥ 100 |
| Product family | Industrial Ethernet |
| Protection degree | IP67 with housing |
| Soldering process |
Reflow soldering
Manual soldering |
| Insulation strength | ≥ 500 MΩ |
| Rated current | 4 A |
| Rated voltage | 72 V |
| Connector standard | IEC 63171-5 |
| Insulating material | LCP |
| Colour | black |
| Colour chart (similar) | RAL 9011 |
| Insulation strength | ≥ 500 MΩ |
| Moisture Level (MSL) | 1 |
| UL 94 flammability rating | V-0 |
| Contact material | Cu-alloy |
| Contact surface | Ni/Au |
| Operating temperature, min. | -40 °C |
| Operating temperature, max. | 85 °C |
| VPE length | 327 mm |
| VPE width | 327 mm |
| VPE height | 52 mm |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_263977) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2795110000) |
| Technical Documentation | [IE-PCB-SPM-P-180-SMD](https://mdcop.weidmueller.com/mediadelivery/asset/900_200640) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002637 |
| ETIM 7.0 | EC002637 |
| ETIM 8.0 | EC002637 |
| ETIM 9.0 | EC002637 |
| ECLASS 9.0 | 27-44-04-02 |
| ECLASS 9.1 | 27-44-04-02 |
| ECLASS 10.0 | 27-44-04-02 |
| ECLASS 11.0 | 27-46-02-01 |
| ECLASS 12.0 | 27-46-02-01 |
| ECLASS 13.0 | 27-46-02-01 |
| ECLASS 14.0 | 27-46-02-01 |
| ROHS | Conform |
