特性
| 版本 | 压接框（汇流排）, 压线框式, 银色, 4 mm², 宽度: 7.4 mm, M 3, 钢 |
| 订货号 | 0322160000 |
| 类型 | ZB 4G GN/GE |
| GTIN (EAN) | 4008190014278 |
| 数量 | 50 PC |
| 深 | 27 mm |
| 深度 (英寸) | 1.063 inch |
| 高度 | 19.5 mm |
| 高度 (英寸) | 0.768 inch |
| 宽度 | 7.4 mm |
| 宽度 (英寸) | 0.291 inch |
| 净重 | 4.948 g |
| 工作温度范围 | For operating temperature range see EC Design Test Certificate / IEC Ex-Certificate of Conformity |
| RoHS 合规状态 | 合规，无例外 |
| REACH SVHC | No SVHC above 0.1 wt% |
| 材料 | 钢 |
| 绝缘材料 | PA |
| 颜色编码 | 银色 |
| ATEX 证书号 | DEMKO03ATEX136028U |
| IECEX 证书号 | IECEXULD13.0005U |
| 导线最大压接面积(ATEX) | 4 mm² |
| 导线最大压接面积 (IECEX) | 4 mm² |
| 工作温度范围 | For operating temperature range see EC Design Test Certificate / IEC Ex-Certificate of Conformity |
| EN 60079-7 标识 | Ex eb II C Gb |
| Ex 2014/34/EU 标签 | II 2 G D |
| 安全提示 |
Installation instructions: The potential equalisation (PE) rail modules are suitable for use in housings in atmospheres with flammable gases and dust. For use in areas with flammable gases, these housings must meet the requirements of EN 60079-0 and EN 60079-7. For use in areas with flammable dust, these housings must meet the requirements of EN 60079-0 and EN 60079-31. When combined with other terminal block ranges and sizes, and when other accessories are used, you must comply with the clearance and creepage distances given. Regarding accessory use, the manufacturer's instructions must be followed. List of restrictions: The PE rail modules are considered one component, with Ex marking when used with the busbar holders of type SH and WEW. When used independently, the above named components are not covered by this certificate. |
| 类型 |
用于 10 x 3 mm 汇流排
用于随后回转 |
| 安装指导 | 直通 (套管) |
| 安装方式 | 旋紧的 |
| 剥线长度 | 16 mm |
| 压接螺钉 | M 3 |
| 导线连接截面积，单股硬导线，最大 | 6 mm² |
| 导线连接截面积，单股硬导线，最小 | 0.5 mm² |
| 联接类型 | 压线框式 |
| 安装指导 | 直通 (套管) |
| 额定横截面 | 4 mm² |
| UR 证书号 | E60693 |
| 最大导线尺寸 工厂接线 (UR) | 12 AWG |
| 最大导线尺寸 现场接线 (UR) | 12 AWG |
| 最小导线尺寸 工厂接线 (UR) | 20 AWG |
| 最小导线尺寸 现场接线 (UR) | 20 AWG |
| 认证/证书/一致性声明 |
[Attestation of Conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_35555)
[UKCA Attestation of conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_255566) [ATEX Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_80376) [IECEx Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_80377) [UKCA Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_255567) |
| 工程数据 | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_58992) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.0322160000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=0322160000) |
| 用户文档 |
[Installation Instruction](https://mdcop.weidmueller.com/mediadelivery/asset/900_80378)
[StorageConditionsTerminalBlocks](https://mdcop.weidmueller.com/mediadelivery/asset/900_87149) |
| 产品目录 | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002848 |
| ETIM 7.0 | EC002848 |
| ETIM 8.0 | EC002848 |
| ETIM 9.0 | EC002848 |
| ECLASS 9.0 | 27-14-11-92 |
| ECLASS 9.1 | 27-14-11-92 |
| ECLASS 10.0 | 27-14-11-92 |
| ECLASS 11.0 | 27-14-11-46 |
| ECLASS 12.0 | 27-14-11-46 |
| ECLASS 13.0 | 27-25-01-16 |
| ECLASS 14.0 | 27-25-01-16 |
| 认证 |      |
| ROHS | 一致 |
| UL File Number Search | [UL 网站](LINK/UL_search.html) |
| UR 证书号 | E60693 |
| cURusEX 证书号 | E184763 |
