HDC 32B TOLU 1M50G CS
Product image
HDC 32B TOLU 1M50G CS
Drawing

HDC 32B TOLU 1M50G CS

Item No. 1983480000
Download data sheet Engineering Support Product Downloads
Accessories 9 Related products 3
Approvals General ordering data Dimensions and weights Environmental Product Compliance Dimensions General data Version Classifications

Approvals

Approvals
![](https://assets.dam.weidmueller.com/assets/api/98e12ea5-58f4-450a-9983-f439987b3951/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/cbf09862-97e9-475d-b71a-c6db1e3e9933/DAP_Master_ICON,w_80,q_80)
ROHS
Conform

General ordering data

Order No.
1983480000
Type
HDC 32B TOLU 1M50G CS
GTIN (EAN)
4032248687800
Qty.
1 items

Dimensions and weights

Depth
110 mm
Depth (inches)
4.331 inch
Height
79 mm
Height (inches)
3.11 inch
Width
82.5 mm
Width (inches)
3.248 inch
Net weight
338.8 g

Environmental Product Compliance

REACH SVHC
Lead 7439-92-1

Dimensions

Cable entry
w. thread
Height of housing B
79 mm
Total length housing
110 mm
Width housing C
82.5 mm

General data

IP65
in plugged condition
Surface finish
Powder coating
UL 94 flammability rating
None

Version

BG
10
Cable entry
w. thread
Clamp version
End-locking clamp
Colour (RAL)
RAL 7035
Cover
without cover
Design
Standard
Design of housing
Plug housing
Cable entry from top
Design of locking system
End-locking clamp, lower side
Installation size
10
Internal thread
M 50
Number of cable entry on top
1
Number of cable entry sideways
0
Number of cable glands
1
Sealing
no sealing
Size of cable entries
M 50
Suitable for ModuPlug®
Yes
Tightening torque
2 Nm
Top part/bottom part/lid
upper part
Type
Plug

Classifications

ETIM 8.0
EC000437
ETIM 9.0
EC000437
ETIM 10.0
EC000437
ECLASS 14.0
27-44-02-02
ECLASS 15.0
27-44-02-02
