MBGE ADPT MOD8,40 POLE 16 FUSES

MBGE ADPT MOD8,40 POLE 16 FUSES

Ürün No. 8000148518
Veri sayfasını indir Ürün İndirmleri
İlgili ürünler 13
General ordering data Dimensions and weights Temperatures Rated data UL Connection data Connection data Ratings data Insulation coordination (EN50178) Classifications

General ordering data

Order No.
8000148518
Type
MBGE ADPT MOD8,40 POLE 16 FUSES
GTIN (EAN)
4099987193429
Кол.
ST

Dimensions and weights

Depth
73,7 mm
Depth (inches)
2,902 inch
Height
238,1 mm
Height (inches)
9,374 inch
Width
27,6 mm
Width (inches)
1,087 inch
Net weight
0,05 g

Temperatures

Temperatura de almacenamiento
-20...70 °C
Operating temperature
-20...50 °C

Rated data UL

Operating temperature UL, max.
50 °C
Operating temperature UL, min.
-20 °C
Storage temperature UL, max.
70 °C
Storage temperature UL, min.
-20 °C
Rated current Imax
40 A
Rated voltage UN
250 V

Connection data

Csatlakozás (terepi oldal)
Modicon 800, 40 poles connector
Number of poles (control side)
40-pole

Connection data

Connection (field side)
Modicon 800, 40 poles connector
Connection to PLC
New PLC terminal block or hardwired
Number of poles (field side)
40 P

Ratings data

Operating voltage
250 V
Corriente máxima por canal
5,5 A
Corrente nominale totale
40 A

Insulation coordination (EN50178)

Rated insulation voltage
300 V
서지 전압 범주
II
Nedsmutsningsgrad
2
Lökőfeszültség-próba (1,2/ 50 μs)
2,5 kV
Napięcie probiercze izolacji AC
1,8 kV

Classifications

ETIM 8.0
EC002584
ETIM 9.0
EC002584
ETIM 10.0
EC002584
ECLASS 14.0
27-33-02-92
ECLASS 15.0
27-33-02-92
