Eigenschappen
| Version | FrontCom, Insert plate, shielded |
| Order No. | 2004810000 |
| Type | IE-FC-DSP-CI/3A/2ST/1D9 |
| GTIN (EAN) | 4050118389289 |
| Qty. | 1 items |
| Height | 23 mm |
| Height (inches) | 0,906 inch |
| Width | 116,5 mm |
| Width (inches) | 4,587 inch |
| Length | 90,5 mm |
| Length (inches) | 3,563 inch |
| Net weight | 144,4 g |
| Operating temperature | -40 °C...70 °C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | Potassium perfluorobutane sulfonate 29420-49-3 |
| SCIP | 8a473a8a-33d4-4318-8088-c28f019e7f77 |
| Material | Polycarbonate PC |
| Product type |
Insert plate
shielded |
| Insert fuse | 1 |
| Insert GFCI /2 x Power US pre-assembled | 1 |
| Insert, data | 2 |
| Signal insert D-Sub 9-pole / VGA / HDMI | 1 |
| Conductor connection cross-section, extremely flexible with wire end ferrule |
|
| Conductor connection cross-section, extremely flexible with wire end ferrule | 1.5 ... 2.5 mm² |
| Conductor connection cross-section, extremely flexible without wire end ferrule | ... |
| Conductor connection cross-section, flexible with wire end ferrule |
|
| Conductor connection cross-section, flexible with wire end ferrule | 1.5 ... 2.5 mm² |
| Conductor connection cross-section, flexible without wire end ferrule | ... |
| Conductor connection cross-section, rigid |
|
| Conductor connection cross-section, rigid | 1.5 ... 4 mm² |
| Stripping length | 9 mm |
| Type of connection | Screw connection |
| GFCI protected US outlet | 2 pieces |
| Housing colour | grey |
| Operating voltage | 125 V |
| Rated current | 20 A |
| Self-test | automatically every 3 seconds |
| Status indication | red LED |
| Trip level, max. | 6 mA |
| Trip level, min. | 4 mA |
| Voltage type | AC |
| Operating voltage | 125 V |
| Voltage type | AC |
| Certificate No. (CSA) | 2000039-80039714 |
| Certificate No. (cURus) | E223801 |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_157184) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.2004810000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2004810000) |
| Product Change Notification |
[202201114 Technical change FrontCom GFCI](https://mdcop.weidmueller.com/mediadelivery/asset/900_249838)
[202201114 Technische Änderung zu FrontCom Vario GFCI](https://mdcop.weidmueller.com/mediadelivery/asset/900_249839) |
| User Documentation | [Designation key / Type key](https://mdcop.weidmueller.com/mediadelivery/asset/900_90847) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000456 |
| ETIM 7.0 | EC000456 |
| ETIM 8.0 | EC000456 |
| ETIM 9.0 | EC000456 |
| ECLASS 9.0 | 27-18-28-06 |
| ECLASS 9.1 | 27-18-92-90 |
| ECLASS 10.0 | 27-18-28-06 |
| ECLASS 11.0 | 27-18-28-06 |
| ECLASS 12.0 | 27-18-28-92 |
| ECLASS 13.0 | 27-18-28-92 |
| ECLASS 14.0 | 27-18-28-92 |
| Approvals |   |
| ROHS | Conform |
| UL File Number Search | [UL Website](https://database.ul.com/cgi-bin/XYV/cgifind/LISEXT/1FRAME/gfilenbr.html) |
| Certificate No. (cURus) | E223801 |
