Özellikler
| Version | Cover hood (terminal), Polyamide 66 |
| Order No. | 0475460000 |
| Type | IK 4 GG ZB4 |
| GTIN (EAN) | 4008190065348 |
| Qty. | 50 adet |
| Depth | 14,5 mm |
| Depth (inches) | 0,571 inch |
| Height | 19 mm |
| Height (inches) | 0,748 inch |
| Width | 6 mm |
| Width (inches) | 0,236 inch |
| Net weight | 0,96 g |
| Continuous operating temp., min. | -50 °C |
| Continuous operating temp., max. | 100 °C |
| REACH SVHC | / |
| Material | Polyamide 66 |
| Insulating material | PA |
| Colour | silver |
| UL 94 flammability rating | V-2 |
| Version | for busbar 10 x 3 mm |
| Installation advice | Busbar |
| TS 35 offset | 39 mm |
| Installation advice | Busbar |
| Operating temperature range, max. | 100 °C |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.0475460000) |
| WSCAD Universe | [WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=0475460000&norm=0) |
| User Documentation | [StorageConditionsTerminalBlocks](https://mdcop.weidmueller.com/mediadelivery/asset/900_87149) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002848 |
| ETIM 7.0 | EC002848 |
| ETIM 8.0 | EC002848 |
| ETIM 9.0 | EC002848 |
| ECLASS 9.0 | 27-14-11-92 |
| ECLASS 9.1 | 27-14-11-92 |
| ECLASS 10.0 | 27-14-11-92 |
| ECLASS 11.0 | 27-14-11-92 |
| ECLASS 12.0 | 27-14-11-92 |
| ECLASS 13.0 | 27-25-03-90 |
| ROHS | Conform |
