Özellikler
| Version | SAI Active, Subbus, Complete modul |
| Order No. | 1938630000 |
| Type | SAI-AU M8 SB 8DIO |
| GTIN (EAN) | 4032248612635 |
| Qty. | 1 adet |
| Height | 32 mm |
| Height (inches) | 1,26 inch |
| Width | 30 |
| Width (inches) | 1,181 inch |
| Length | 180 mm |
| Length (inches) | 7,087 inch |
| Net weight | 297 g |
| Storage temperature | -25 °C...85 °C |
| Operating temperature | 0 °C...60 |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c, 7a, 7cI |
| REACH SVHC |
Lead 7439-92-1
Potassium perfluorobutane sulfonate 29420-49-3 |
| SCIP | 30ca4bfe-b33c-43ed-b218-3746bc09f6a6 |
| Connection to Subbus (SUB-IN) |
1 x M8 plug 4-pole
A-coded |
| Connection to Subbus (SUB-OUT) |
1 x M8 female 4-pole
A-coded |
| I/O connections | 8 x M8 socket 3-pole |
| Supply voltage (AUX-IN) |
1x M12 plug 5-pole
A-coded |
| Diagnosis indication | red |
| Input current, high | 2 mA to 15 mA in accordance with EN 61131-2 Type 1 |
| Input current, low | < 15 mA in accordance with EN 61131-2 Type 1 |
| Input filter |
1 ms
3 ms 5 ms 10 ms configurable |
| Input voltage, high | >15 V in accordance with EN 61131-2 Type 1 |
| Input voltage, low | <5 V in accordance with EN 61131-2 Type 1 |
| Permitted input voltage | -30 V to +30 V (protected against polarity reversal) |
| Separation of potentials to module electronics | none |
| Diagnosis indication | red |
| max. current-carrying capacity per output signal | 0.5 A |
| Max. total current outputs | 4 A |
| Output voltage, high | Supply voltage less 0.7 V DC |
| Output voltage, low | 0 V DC |
| Separation of potentials to module electronics | none |
| Short-circuit proof | Yes, cut-off for short circuit and error message |
| Switching frequency, inductive load | max. 1 Hz |
| Switching frequency, lamp load | max. 8 Hz |
| Switching frequency, resistive load | max. 100 Hz |
| Certificate |
CE
cULus |
| Earth | < 200 g |
| Housing main material |
Pocan
PBT |
| Protection degree | IP67 |
| UL 94 flammability rating | 5VA |
| Contact load | Per PIN max. 4 A |
| Limits | 18 V DC ... 30 V DC |
| Max. total current module | 8 A |
| Operating voltage | 24 V |
| Reverse polarity protection | Yes |
| Approval/Certificate/Document of Conformity |
[Declaration_of_Conformity_DE_PN45](https://mdcop.weidmueller.com/mediadelivery/asset/900_41950)
[CE Declaration of Conformity - DE](https://mdcop.weidmueller.com/mediadelivery/asset/900_287398) [UKCA Declaration of Conformity - EN](https://mdcop.weidmueller.com/mediadelivery/asset/900_287402) |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_164135) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1938630000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1938630000) |
| User Documentation |
[MAN UR67 SAI-Aktive Universal Pro DE](https://mdcop.weidmueller.com/mediadelivery/asset/900_313788)
[MAN UR67 SAI-Active Universal Pro EN](https://mdcop.weidmueller.com/mediadelivery/asset/900_313789) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC001599 |
| ETIM 7.0 | EC001599 |
| ETIM 8.0 | EC001599 |
| ETIM 9.0 | EC001599 |
| ECLASS 9.0 | 27-24-26-04 |
| ECLASS 9.1 | 27-24-26-04 |
| ECLASS 10.0 | 27-24-26-04 |
| ECLASS 11.0 | 27-24-26-04 |
| ECLASS 12.0 | 27-24-26-04 |
| ECLASS 13.0 | 27-24-26-04 |
| ECLASS 14.0 | 27-24-26-04 |
| Approvals |   |
| ROHS | Conform |
| UL File Number Search | [UL Website](LINK/UL_search.html) |
| Certificate no. (cULus) | E141197 |
