Özellikler
| Version | M8, LED: , LED initiator: , Wiring type: |
| Order No. | 2662450000 |
| Type | SAIEND 1/4 M8G 3P |
| GTIN (EAN) | 4050118677379 |
| Qty. | 1 adet |
| Net weight | 5 g |
| Operating temperature | -25 - 85°C |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 1c533b66-fcff-4da5-b89f-fd55fbf5cb55 |
| Protection degree | IP67 |
| Number of poles | 3 |
| Connection thread | M8 |
| Pollution severity | 3 |
| Plugging cycles | ≥ 100 |
| Number of poles | 3 |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_253918) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2662450000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000448 |
| ETIM 7.0 | EC000448 |
| ETIM 8.0 | EC000448 |
| ETIM 9.0 | EC000448 |
| ECLASS 9.0 | 19-07-04-03 |
| ECLASS 9.1 | 19-17-01-90 |
| ECLASS 10.0 | 19-07-04-03 |
| ECLASS 11.0 | 19-07-04-03 |
| ECLASS 12.0 | 19-07-04-03 |
| ECLASS 13.0 | 19-07-04-03 |
| Approvals |   |
