Özellikler
| Version | Cutting, stripping and crimping tool, Crimping tool for wire-end ferrules, 0.5mm², 2.5mm², Trapezoidal crimp |
| Order No. | 9020000000 |
| Type | STRIPAX PLUS 2.5 |
| GTIN (EAN) | 4008190067267 |
| Qty. | 1 adet |
| Width | 210 mm |
| Width (inches) | 8,268 inch |
| Net weight | 248,63 g |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 2159813b-98fd-4068-b62a-bc89a046c012 |
| Description of article | (1)Crimping tool |
| Version | Mechanical, without interchangeable inserts |
| Conductor cross-section, max. AWG | AWG 14 |
| Conductor cross-section, min. AWG | AWG 20 |
| Crimping range, max. | 2,5 mm² |
| Crimping range, min. | 0,5 mm² |
| Type of contact | Strips of linked wire-end ferrules |
| Crimping type/profile | Trapezoidal crimp |
| Wire end ferrules cross-section, max. | 2,5 mm² |
| Wire end ferrules cross-section, min. | 0,5 mm² |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_66799) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=9020000000) |
| WSCAD Universe | [WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=9020000000&norm=0) |
| Product Change Notification |
[Technische Änderung für Crimpwerkzeug stripax plus 2.5](https://mdcop.weidmueller.com/mediadelivery/asset/900_310211)
[Technical change to Crimping tool Stripax plus 2.5](https://mdcop.weidmueller.com/mediadelivery/asset/900_310212) |
| User Documentation | [Manual](https://mdcop.weidmueller.com/mediadelivery/asset/900_101164) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002109 |
| ETIM 7.0 | EC002109 |
| ETIM 8.0 | EC002109 |
| ETIM 9.0 | EC002109 |
| ECLASS 9.0 | 21-04-37-06 |
| ECLASS 9.1 | 21-04-37-06 |
| ECLASS 10.0 | 21-04-37-06 |
| ECLASS 11.0 | 21-04-37-06 |
| ECLASS 12.0 | 21-04-37-06 |
| ECLASS 13.0 | 21-04-37-06 |
Aksesuarlar
-
Ürün No.:9004360000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, blue
-
Ürün No.:9004370000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 11 mm, 8 mm, grey
-
-
-
Ürün No.:9004350000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, black
-
Ürün No.:9004340000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, red
-
Ürün No.:9021960000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, black
-
Ürün No.:9004310000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, Light Blue
-
Ürün No.:9004300000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, grey
-
Ürün No.:9004290000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, white
-
Ürün No.:9004320000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, yellow
-
Ürün No.:9004330000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, red
-
Ürün No.:9021950000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, red
-
Ürün No.:9004270000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, orange
-
Ürün No.:9021930000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, white
-
Ürün No.:9004280000Ambalaj birimi:500 adet
Wire-end ferrule, Standard, 10 mm, 8 mm, white
aksesuarıdır
-
Ürün No.:9028770000Ambalaj birimi:1 adet
Assortment crimping tool, Crimping tool: STRIPAX-Plus, Stripping tool: STRIPAX-Plus, Crimping range, min.: 0.5, Colour code: Weidmüller
-
Ürün No.:9028780000Ambalaj birimi:1 adet
Assortment crimping tool, Crimping tool: STRIPAX-Plus, Stripping tool: STRIPAX-Plus, Crimping range, min.: 0.5, Colour code: DIN
-
Ürün No.:9028790000Ambalaj birimi:1 adet
Assortment crimping tool, Crimping tool: STRIPAX-Plus, Stripping tool: STRIPAX-Plus, Crimping range, min.: 0.5, Colour code: Miscellaneous
