特性
| 版本 | 受保护组件, SAI有源, 附件, 传感器/执行器接插件 |
| 订货号 | 1784770000 |
| 类型 | SAIEND PB M12 4P B-COD |
| GTIN (EAN) | 4032248191857 |
| 数量 | 1 PC |
| 净重 | 10 g |
| 工作温度 | -25 °C...85 °C |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 1c533b66-fcff-4da5-b89f-fd55fbf5cb55 |
| RoHS 合规状态 | 合规，有例外 |
| RoHS 豁免（如适用/已知） | 6c |
| 回路数 | 4 |
| 插拔次数 | ≥ 100 |
| 污染等级 | 3 |
| 类型 | 针式 直 |
| 联接螺纹 | M12 |
| 防护等级 | IP67 |
| 工程数据 | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_181283) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1784770000) |
| 产品更改通知 | [318301](https://mdcop.weidmueller.com/mediadelivery/asset/900_318301) |
| 产品目录 | [Catalogues in PDF-format](LINK/Catalog.html) |
| 样本 |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC000448 |
| ETIM 7.0 | EC000448 |
| ETIM 8.0 | EC000448 |
| ETIM 9.0 | EC000448 |
| ECLASS 9.0 | 19-07-04-03 |
| ECLASS 9.1 | 19-17-01-90 |
| ECLASS 10.0 | 19-07-04-03 |
| ECLASS 11.0 | 19-07-04-03 |
| ECLASS 12.0 | 19-07-04-03 |
| ECLASS 13.0 | 19-07-04-03 |
| ECLASS 14.0 | 19-07-04-03 |
| 认证 |   |
| ROHS | 一致 |
