Egenskaber
| Version | Hood version with M25 outlet, M12, 30 V, A-coded, LED: Yes, LED initiator: No, Wiring type: PNP |
| Order No. | 1740193000 |
| Type | SAI-8-MHD 5P M12 OL |
| GTIN (EAN) | 4032248298938 |
| Qty. | 1 Styk |
| Depth | 152 mm |
| Depth (inches) | 5,984 inch |
| Height | 53 mm |
| Height (inches) | 2,087 inch |
| Width | 60 mm |
| Width (inches) | 2,362 inch |
| Net weight | 565 g |
| Operating temperature | -20 - 90°C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Conductor O.D., min. | 14 mm |
| Conductor O.D., max. | 18 mm |
| Cable glands | M 25 |
| Distributor outlet | Hood version with M25 outlet |
| Rated voltage, min. | 10 V |
| Rated voltage, max. | 30 V |
| Max. current-carrying capacity per slot | 4 A |
| Total current | 10 A |
| Electrical isolation available | Yes |
| Insulation strength | 109 Ω |
| Plug-in station coding | A-coded |
| Protection degree | IP68 |
| Number of poles | 5 |
| Number of contact sockets | 8 |
| Connection thread | M12 |
| LED | Yes |
| LED initiator | No |
| LED colour for indicating operation | green |
| Housing main material |
Pocan (base module)
Zinc diecast (hood) |
| Contact material | CuZn |
| Contact surface | Gold-plated |
| Conductor O.D., max. | 18 mm |
| Conductor O.D., min. | 14 mm |
| Number of poles | 5 |
| Suitable for cable carriers | No |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_104044) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1740193000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures | [FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC002585 |
| ETIM 7.0 | EC003558 |
| ETIM 8.0 | EC003558 |
| ETIM 9.0 | EC003558 |
| ECLASS 9.0 | 27-44-01-08 |
| ECLASS 9.1 | 27-44-01-08 |
| ECLASS 10.0 | 27-44-01-11 |
| ECLASS 11.0 | 27-44-01-11 |
| ECLASS 12.0 | 27-44-01-11 |
| ECLASS 13.0 | 27-44-01-11 |
| ECLASS 14.0 | 27-44-01-11 |
| ROHS | Conform |
