Egenskaber
| Version | Pressing tool, 4-indent crimp |
| Order No. | 1381700000 |
| Type | SAI-TMC-PD |
| GTIN (EAN) | 4050118183856 |
| Qty. | 1 Styk |
| Depth | 23,75 mm |
| Depth (inches) | 0,935 inch |
| Length | 23,6 mm |
| Length (inches) | 0,929 inch |
| Net weight | 22 g |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Version | Miscellaneous |
| Conductor cross-section, max. AWG | AWG 20 |
| Conductor cross-section, min. AWG | AWG 28 |
| Type of contact | Turned contacts |
| adjustable crimping range AWG |
AWG 20
AWG 22 AWG 24 AWG 26 AWG 28 |
| Crimping type/profile | 4-indent crimp |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC000168 |
| ETIM 7.0 | EC000168 |
| ETIM 8.0 | EC000168 |
| ETIM 9.0 | EC000168 |
| ECLASS 9.0 | 21-04-38-11 |
| ECLASS 9.1 | 21-04-38-11 |
| ECLASS 10.0 | 21-04-38-11 |
| ECLASS 11.0 | 21-04-38-11 |
| ECLASS 12.0 | 21-04-38-11 |
| ECLASS 13.0 | 21-04-38-11 |
| ECLASS 14.0 | 21-04-38-11 |
Er tilbehør til
ConnectorsCircular ConnectorsM12 connectorsSignalCrimp connectionShield cable gland
