Ürün No. 1390850000
Veri sayfasını indir Ürün İndirmleri
Aksesuarlar 2 İlgili ürünler 8
Approvals General ordering data Dimensions and weights Temperatures Environmental Product Compliance General data Rated data acc. to IEC 60598-1 Classifications

Approvals

Omologazioni
![](https://assets.dam.weidmueller.com/assets/api/98e12ea5-58f4-450a-9983-f439987b3951/DAP_Master_ICON,w_80,q_80)
![](https://assets.dam.weidmueller.com/assets/api/0d1637a4-c7dd-4915-8bc8-4c9de8d8b393/DAP_Master_ICON,w_80,q_80)
ROHS
Conform
UL File Number Search
[UL Website](https://database.ul.com/cgi-bin/XYV/cgifind/LISEXT/1FRAME/gfilenbr.html)
N° Certificato (cULus)
E345151

General ordering data

Rendelési szám
1390850000
Típus
BG GHDE LED TL PT6
GTIN (EAN)
4050118190977

Dimensions and weights

Magasság
46 mm
Height (inches)
1,811 inch
Szélesség
104 mm
Width (inches)
4,094 inch
Lunghezza
181 mm
Length (inches)
7,126 inch
Net weight
616 g

Temperatures

Temperatura d'esercizio
-40 °C...60 °C

Environmental Product Compliance

Stato conformità RoHS
Compliant with exemption
Esenzione RoHS (se applicabile/nota)
6c, 7a, 7cI
REACH SVHC
Lead 7439-92-1
Potassium perfluorobutane sulfonate 29420-49-3
SCIP
730dada5-5c8b-4737-8e0b-847db05af8d5

General data

Altitude
≤ 3000 m
Amplitude of acceleration
5 m/s² (@ 9-200 Hz)
Amplitude of deflection
1.5 mm (2-9 Hz)
Hållfasthet mot stötar EN 60721-3
Class 3M3
Light colour (CCT)
6000K
Peak acceleration, type L
70 m/s²
Short-circuit protection
internal
Silicone
No
Tipo di cavi
Heluwind WK 103w-T 3G1,5 (AD 8 mm)
UL 94 가연성 등급
V-0
Вибростойкость EN 60721-3-3
Class 3M3
EN 60721-3-3
결선 유형
Open cable end/length 2 m
보호 등급
IP65 with corresponding housing
보호 등급
II
서지 전압 범주
II
오염 심각도
2
장착 위치, 설치 알림
Arbitrary
절연 전압
< 500 V (housing/PE)
할로겐
yes (PVC cable)
회로 차단기
< 10 A

Rated data acc. to IEC 60598-1

Input voltage
100…265 V DC (45...65 Hz)
Inrush current
0.5 A @ 0.1 ms
Power loss
< 2 W
Power rating
7 W
Rated voltage
265 V

Classifications

ETIM 8.0
EC001959
ETIM 9.0
EC001959
ETIM 10.0
EC001959
ECLASS 14.0
27-11-06-40
ECLASS 15.0
27-11-06-40
