CableLine, 슬리브 x 5 mm, PVC, 컬러 코드: 투명, 컨덕터 O.D.: 2.5 - 5 mm

Ürün No. 1889560000
Veri sayfasını indir Product Downloads Engineering Support
İlgili ürünler 4
Approvals Dati generali per l’ordinazione Wymiary i masa Temperatures Termékek környezetvédelmi megfelelősége General data Conductor and cable markers Classifications

Approvals

ROHS
Conform

Dati generali per l’ordinazione

Version
CableLine, 슬리브 x 5 mm, PVC, 컬러 코드: 투명, 컨덕터 O.D.: 2.5 - 5 mm
Order No.
1889560000
Type
CLI T 1-30
GTIN (EAN)
4032248496365
Qty.
200 adet

Wymiary i masa

Height
30 mm
Bygghöjd (tum)
1,181 inch
Width
5 mm
Width (inches)
0,197 inch
Net weight
0,51 g

Temperatures

Operating temperature range
-30...80 °C

Termékek környezetvédelmi megfelelősége

RoHS Compliance Status
Conforme senza esenzione
REACH SVHC
No SVHC above 0.1 wt%

General data

Basic material
PVC
Colour
Transparent
Halogen
Yes
Number per roll
200
Operating temperature range
-30...80 °C
Operating temperature range, min.
-30 °C
Printed characters
without
Recommended industries
Verkehrstechnik
Maschinenbau
Rozsah provozní teploty, max.
80 °C
Type of printing
sin imprimir
UL 94 flammability rating
V-0
Width
5 mm

Conductor and cable markers

Conductor cross-section, max.
6 mm²
Conductor cross-section, min.
0,75 mm²
Conductor O.D.
2.5 - 5 mm
Conductor O.D., max.
5 mm
Conductor O.D., min.
2,5 mm
Cross-section for connected wire
0.75 - 6 mm²
Halogen
Yes

Classifications

ETIM 8.0
EC001530
ETIM 9.0
EC001530
ETIM 10.0
EC001530
ECLASS 14.0
27-28-11-02
ECLASS 15.0
27-28-11-02
