Eigenschappen
| Order No. | 1505530000 |
| Type | FAD BLK 7 2HE20 |
| GTIN (EAN) | 4050118319545 |
| Qty. | 1 items |
| Depth | 37 mm |
| Depth (inches) | 1,457 inch |
| Height | 24 mm |
| Height (inches) | 0,945 inch |
| Width | 209 mm |
| Width (inches) | 8,228 inch |
| Net weight | 187 g |
| Storage temperature | -40...60 °C |
| Operating temperature | -25...50 °C |
| Connection (field side) | 2 x Connector according IEC60603-13/DIN41651 20 p |
| Connection (field side) | 2 x Connector according IEC60603-13/DIN41651 20 p |
| Operating voltage | 50 V AC / 70 V DC |
| According to | DIN EN 50178 |
| Rated insulation voltage | < 50 V AC |
| Surge voltage category | II |
| Pollution severity level | 2 |
| Pulse voltage test (1,2/50μs) | 0,5 kV |
| Insulation test voltage AC | 0,35 kV |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1505530000) |
| WSCAD Universe | [WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=1505530000&norm=0) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002584 |
| ETIM 7.0 | EC002584 |
| ETIM 8.0 | EC002584 |
| ETIM 9.0 | EC002584 |
| ECLASS 9.0 | 27-33-02-92 |
| ECLASS 9.1 | 27-24-22-92 |
| ECLASS 10.0 | 27-33-02-92 |
| ECLASS 11.0 | 27-33-02-92 |
| ECLASS 12.0 | 27-33-02-92 |
| ECLASS 13.0 | 27-33-02-92 |
| Approvals |  |
| ROHS | Conform |
