IE-BS-V01M-LCD-MM-C
IE-BS-V01M-LCD-MM-C
Installation cut-out
Mounting cut-out: 1. With central screw connection / 2. For mounting with four M3 screws
IE-BS-V01M-LCD-MM-C
Detailed drawing
Wall thickness when using the central screw connection

IE-BS-V01M-LCD-MM-C

Оптоволоконный разъем, IP67, Variant 1, соединение LC Duplex, Многомодовый

Produkt ID 1964440000
Download datablad Engineering Support Product Downloads
Tilbehør 1 Anvendte produkter 2
Approvals Ogólne dane zamówieniowe Dimensioni e pesi Temperatures Zgodność produktu z wymogami środowiska naturalnego General data General standards Classifications

Approvals

ROHS
Conform

Ogólne dane zamówieniowe

Version
Оптоволоконный разъем, IP67, Variant 1, соединение LC Duplex, Многомодовый
Order No.
1964440000
Type
IE-BS-V01M-LCD-MM-C
GTIN (EAN)
4032248649051
Qty.
10 Styk

Dimensioni e pesi

Depth
33,3 mm
Byggdjup (tum)
1,311 inch
Height
32 mm
Height (inches)
1,26 inch
Width
32 mm
Width (inches)
1,26 inch
Net weight
60,1 g

Temperatures

Operating temperature
-40 °C...70 °C

Zgodność produktu z wymogami środowiska naturalnego

RoHS Compliance Status
Zgodne, z wyłączeniem
RoHS Exemption (if applicable/known)
6c
REACH SVHC
Lead 7439-92-1
6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol 119-47-1
SCIP
c1a8d9e9-fd0c-4258-8c31-7317a7b4ce18

General data

Colour
Miscellaneous
Connection 1
LC Duplex
Connection 2
LC Duplex
Description of article
Version 1, LC Duplex coupling
Fibre type
Multimode
Housing main material
Zinc diecast
Insertion loss
≤ 0.4 dB
Plugging cycles
500
Protection degree
IP67
Return loss (attenuation)
≥ 30 dB

General standards

Connector standard
IEC 61076-3-106 Var. 1
IEC 61754-20

Classifications

ETIM 8.0
EC000752
ETIM 9.0
EC000752
ETIM 10.0
EC000752
ECLASS 14.0
19-17-01-16
ECLASS 15.0
19-17-01-16
