MBGE ADPT FOR CLX TBCH

MBGE ADPT FOR CLX TBCH

Ürün No. 8000168697
Veri sayfasını indir Ürün İndirmleri
İlgili ürünler 2
General ordering data Mått och vikter Temperatures Caractéristiques nominales UL Anschluss Daten Údaje o připojení Ratings data Insulation coordination (EN50178) Classifications

General ordering data

Order No.
8000168697
Type
MBGE ADPT FOR CLX TBCH
GTIN (EAN)
4099987803595
Množství
ST

Mått och vikter

Depth
81,6 mm
Depth (inches)
3,213 inch
Height
142,4 mm
Height (inches)
5,606 inch
Width
34,5 mm
Width (inches)
1,358 inch
Net weight
1.000 g

Temperatures

Storage temperature
-20...70 °C
Operating temperature
-20...50 °C

Caractéristiques nominales UL

Operating temperature UL, max.
50 °C
Operating temperature UL, min.
-20 °C
Storage temperature UL, max.
70 °C
Storage temperature UL, min.
-20 °C
Rated current Imax
40 A
Rated voltage UN
250 V

Anschluss Daten

Connection (field side)
MBGE ADPT FOR CLX TBCH (METAL)

Údaje o připojení

Connection (field side)
MBGE ADPT FOR CLX TBCH (METAL)
Connection to PLC
Nouveau bloc de jonction API ou câblé

Ratings data

Operating voltage
250 V
Max. current per channel
8,6 A
Total operating current
40 A

Insulation coordination (EN50178)

Rated insulation voltage
300 V
Surge voltage category
II
Závažnost úrovně znečištění
2
Pulse voltage test (1,2/50μs)
2,5 kV
Insulation test voltage AC
1,8 kV

Classifications

ETIM 8.0
EC002584
ETIM 9.0
EC002584
ETIM 10.0
EC002584
ECLASS 14.0
27-33-02-92
ECLASS 15.0
27-33-02-92
