Özellikler
| Version | HDC insert, Male, 400 V, 40 A, Number of poles: 2, Crimp contact, Size: 1 |
| Order No. | 3103500000 |
| Type | HDC HQ 2 MC |
| GTIN (EAN) | 4099987151221 |
| Qty. | 1 adet |
| Depth | 21 mm |
| Depth (inches) | 0,827 inch |
| Height | 40 mm |
| Height (inches) | 1,575 inch |
| Net weight | 18,3 g |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Height of plug | 21 mm |
| BG | 1 |
| Colour | grey |
| Insulating material | PC |
| Number of poles | 2 |
| Plugging cycles | ≥ 500 |
| Pollution severity | 3 |
| Rated current (DIN EN 61984) | 40 A |
| Rated impulse voltage (DIN EN 61984) | 6 kV |
| Rated voltage (DIN EN 61984) | 400 V |
| Series | HQ |
| Size | 1 |
| Surge voltage category | III |
| Type | Male |
| Type of connection | Crimp contact |
| UL 94 flammability rating | V-0 |
| Protection degree | IP20 |
| Connection type PE | Crimp connection |
| Stripping length according to the cable diameter |
|
| BG | 1 |
| Conductor cross-section, max. | 6 mm² |
| Conductor cross-section, min. | 1,5 mm² |
| Size | 1 |
| Type of connection | Crimp contact |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_322675) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002312 |
| ETIM 7.0 | EC002312 |
| ETIM 8.0 | EC000438 |
| ETIM 9.0 | EC000438 |
| ECLASS 9.0 | 27-44-02-92 |
| ECLASS 9.1 | 27-44-02-18 |
| ECLASS 10.0 | 27-44-02-92 |
| ECLASS 11.0 | 27-44-02-92 |
| ECLASS 12.0 | 27-44-02-92 |
| ECLASS 13.0 | 27-44-02-92 |
| ECLASS 14.0 | 27-44-02-92 |
| ROHS | Conform |
