Özellikler
| Version | Built-in plugs, M12, Female socket, straight, Mounting thread: M 16 x 1.5, Number of poles: 5, Strand / cable length: 0.2 m, Rear panel mounting |
| Order No. | 2968030000 |
| Type | SAIE-M12SK-5-0.2VHM16-2.5 |
| GTIN (EAN) | 4099986779433 |
| Qty. | 1 adet |
| Net weight | 40 g |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c |
| REACH SVHC | Lead 7439-92-1 |
| Coding | K-coded |
| Contact surface | Gold-plated |
| Housing main material | Zinc diecast |
| Insulation strength | ≥ 100 MΩ |
| Number of poles | 5 |
| Plugging cycles | ≥ 100 |
| Pollution severity | 3 |
| Protection degree |
IP65
IP67 IP68 when screwed in |
| Rated current | 12 A |
| Rated voltage | 630 V |
| Temperature range of housing | -40 … +85 ° C |
| Connector standard | IEC 61076-2-111 |
| AF size | 19 mm |
| Coding | K-coded |
| Connection thread | M12 |
| Contact surface | Gold-plated |
| Core cross-section | 2,5 mm² |
| Housing main material | Zinc diecast |
| Insulation strength | ≥ 100 MΩ |
| Mounting thread | M 16 x 1.5 |
| Number of poles | 5 |
| Plugging cycles | ≥ 100 |
| Pollution severity | 3 |
| Protection degree |
IP65
IP67 IP68 when screwed in |
| Rated current | 12 A |
| Rated voltage | 630 V |
| Strand / cable length | 0,2 m |
| Temperature range of housing | -40 … +85 ° C |
| Type of mounting | Rear panel mounting |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002635 |
| ETIM 7.0 | EC003570 |
| ETIM 8.0 | EC003570 |
| ETIM 9.0 | EC003570 |
| ECLASS 9.0 | 27-44-01-03 |
| ECLASS 9.1 | 27-44-01-03 |
| ECLASS 10.0 | 27-44-01-03 |
| ECLASS 11.0 | 27-44-01-03 |
| ECLASS 12.0 | 27-44-01-03 |
| ECLASS 13.0 | 27-44-01-03 |
| ECLASS 14.0 | 27-44-01-03 |
| Approvals |  |
| ROHS | Conform |
| UL File Number Search | [UL Website](LINK/UL_search.html) |
| Certificate no. (cULus) | E310075 |
