KLIPPON K3 MOPL 0716 MSZN INNU

KLIPPON K3 MOPL 0716 MSZN INNU

Klippon K (aluminium empty enclosure), Empty enclosure, straight, Height: 44 mm, Width: 156 mm, Depth: 1.5 mm, Basic material: Sheet steel, galvanized, silver

Product ID 8000188266
Gegevensblad downloaden Engineeringondersteuning Productdownloads
Verwante producten 37
General ordering data Dimensions and weights Certificate numbers enclosure General information General information on accessories Classifications

General ordering data

Version
Klippon K (aluminium empty enclosure), Empty enclosure, straight, Height: 44 mm, Width: 156 mm, Depth: 1.5 mm, Basic material: Sheet steel, galvanized, silver
Order No.
8000188266
Type
KLIPPON K3 MOPL 0716 MSZN INNU
GTIN (EAN)
4069165062250
Qty.
1 items

Dimensions and weights

Depth
1,5 mm
Depth (inches)
0,059 inch
Height
44 mm
Height (inches)
1,732 inch
Width
156 mm
Width (inches)
6,142 inch
Net weight
72,25 g

Certificate numbers enclosure

Declaration of Conformatiy No. (DoC LVD)
DE PS2410 160412 001ISS03

General information

Areas of use
Building systems and technology
Explosive risk zone
Process industry
Transportation
Basic material
Sheet steel
Installation advice
Mounting plate
Material thickness
1,5 mm
Surface finish
galvanized
Type of fixing
M4 screw (< 4 mm)

General information on accessories

Basic material
Sheet steel
Material thickness
1,5 mm
Solder eyelet hole diameter (D)
7 mm
Surface finish
galvanized
Type of fixing
M4 screw (< 4 mm)

Classifications

ETIM 8.0
EC000213
ETIM 9.0
EC000213
ETIM 10.0
EC000213
ECLASS 14.0
27-40-06-39
ECLASS 15.0
27-40-06-39
