Özellikler
| Version | Connecting plug, Plug, IP67, Cat.6A / Class EA (ISO/IEC 11801 2010), Variant 6 to IEC 61076-3-106 |
| Order No. | 8808380000 |
| Type | IE-P-IP67 |
| GTIN (EAN) | 4032248505968 |
| Qty. | 1 adet |
| Net weight | 29 g |
| Operating temperature | -40 °C...70 °C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Connection 1 | RJ45 |
| Connection 2 | IDC |
| Description of article | Plug |
| Wiring | EIA/TIA T568 A |
| Colour | Light Grey |
| Housing main material |
PA 66
UL 94: V-0 |
| Category | Cat.6A / Class EA (ISO/IEC 11801 2010) |
| Contact surface | Gold over nickel |
| Type of mounting |
Floor-mounted
for exposed connections Wall mounting |
| Shielding | 360° shield contact |
| Protection degree | IP67 |
| Plugging cycles | 750 |
| Certificate No. (DNV) | TAE00003EW |
| Connector standard |
IEC 61076-3-106 Var. 6
IEC 60603-7-5 |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_261938) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=8808380000) |
| User Documentation |
[MAN IE GUIDE DE](https://mdcop.weidmueller.com/mediadelivery/asset/900_40065)
[MAN IE GUIDE EN](https://mdcop.weidmueller.com/mediadelivery/asset/900_40066) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) [PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) |
| ETIM 6.0 | EC001121 |
| ETIM 7.0 | EC001121 |
| ETIM 8.0 | EC001121 |
| ETIM 9.0 | EC001121 |
| ECLASS 9.0 | 27-44-03-90 |
| ECLASS 9.1 | 27-44-03-90 |
| ECLASS 10.0 | 27-44-03-90 |
| ECLASS 11.0 | 27-44-03-90 |
| ECLASS 12.0 | 27-44-03-90 |
| ECLASS 13.0 | 27-44-03-90 |
| ECLASS 14.0 | 27-44-03-90 |
| Approvals |  |
| ROHS | Conform |
Aksesuarlar
-
-
Ürün No.:1963580000Ambalaj birimi:100 adet
RJ45 crimp plug, Plug without bending protection sleeve, Cat.6A / Class EA (ISO/IEC 11801 2010)
ToolsCrimping tools... for modular plug-in connectors
ConnectorsIndustrial Ethernet ConnectorsRJ45, Hybrid & USB connectorsIP20RJ45 crimp
aksesuarıdır
-
Ürün No.:8808370000Ambalaj birimi:1 adet
Connecting plug, Junction box, IP67, Cat.6A / Class EA (ISO/IEC 11801 2010), Variant 6 to IEC 61076-3-106
ConnectorsIndustrial Ethernet ConnectorsJunction boxes / connectorsV6 - plastic
Karşı parçalar
-
Ürün No.:8808440000Ambalaj birimi:1 adet
Mounting flange, RJ45 module flange, straight, Cat.6A / Class EA (ISO/IEC 11801 2010), IP67
-
Ürün No.:8808450000Ambalaj birimi:1 adet
Mounting flange, Coupling flange, straight, Cat.6A / Class EA (ISO/IEC 11801 2010), IP67
-
Ürün No.:8829440000Ambalaj birimi:1 adet
Mounting flange, Coupling flange, 90° up, Cat.6 (ISO/IEC 11801), IP67
-
Ürün No.:8829450000Ambalaj birimi:1 adet
Mounting flange, Coupling flange, 90° down, Cat.6 (ISO/IEC 11801), IP67
ConnectorsIndustrial Ethernet ConnectorsRJ45, Hybrid & USB connectorsIP67V6 SnapInSets - RJ45
