Egenskaber
| Version | Cross-connector (terminal), Plugged, grey, 215 A, Number of poles: 2, Pitch in mm (P): 39.50, Insulated: Yes, Width: 7 mm |
| Order No. | 1561940000 |
| Type | WQB WPD X06/2 |
| GTIN (EAN) | 4050118367126 |
| Qty. | 3 Styk |
| Width | 7 mm |
| Width (inches) | 0,276 inch |
| Net weight | 5,5 g |
| Storage temperature | -25 °C...55 °C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Colour | grey |
| Version | Cross-connector |
| Explosion-tested version | No |
| Type of fixing | Plugged |
| Pitch in mm (P) | 39,5 mm |
| Number of poles | 2 |
| Rated voltage | 400 V |
| Rated current | 215 A |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_304512) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1561940000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1561940000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000489 |
| ETIM 7.0 | EC000489 |
| ETIM 8.0 | EC000489 |
| ETIM 9.0 | EC000489 |
| ECLASS 9.0 | 27-14-11-40 |
| ECLASS 9.1 | 27-14-11-40 |
| ECLASS 10.0 | 27-14-11-40 |
| ECLASS 11.0 | 27-14-11-40 |
| ECLASS 12.0 | 27-14-11-40 |
| ECLASS 13.0 | 27-25-03-03 |
| ECLASS 14.0 | 27-25-03-03 |
| ROHS | Conform |
Er tilbehør til
-
Produkt ID:2518570000Pakningsenhed:1 Styk
Potential distributor terminal, Screw connection, blue, 70 mm², 215 A, 1000 V, Number of connections: 6, Number of levels: 1, Mounting plate, TS 35, V-0, Wemid
-
Produkt ID:1562210000Pakningsenhed:1 Styk
Potential distributor terminal, Screw connection, Light Grey, 70 mm², 215 A, 1000 V, Number of connections: 6, Number of levels: 1, Mounting plate, TS 35, V-0, Wemid
-
Produkt ID:2725340000Pakningsenhed:1 Styk
Potential distributor terminal, Screw connection, red, 70 mm², 215 A, 1000 V, Number of connections: 6, Number of levels: 1, Mounting plate, TS 35, V-0, Wemid
-
Produkt ID:2725440000Pakningsenhed:1 Styk
Potential distributor terminal, Screw connection, black, 70 mm², 215 A, 1000 V, Number of connections: 6, Number of levels: 1, Mounting plate, TS 35, V-0, Wemid
Terminal BlocksApplication rangePower distributionClamping yoke technologyPhase Distribution Blocks70 mm²
