Properties
| Version | Mounting rail housing orange, End plate DIN mounting rail right, Width: 10 mm |
| Order No. | 2064300000 |
| Type | RF RS 70 RE/A5/O.SG 1665 |
| GTIN (EAN) | 4008190210625 |
| Qty. | 1 items |
| Depth | 28.55 mm |
| Depth (inches) | 1.124 inch |
| Height | 70 mm |
| Height (inches) | 2.756 inch |
| Width | 10 mm |
| Width (inches) | 0.394 inch |
| Net weight | 5.55 g |
| REACH SVHC | / |
| RoHS Compliance Status | Compliant without exemption |
| Comparative Tracking Index (CTI) | 600 ≤ CTI |
| Insulating material | PA 66 |
| UL 94 flammability rating | V-2 |
| Colour | orange |
| Colour chart (similar) | RAL 2000 |
| Encapsulation option | No |
| Protection degree | IP00 |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL ANALO.SIGN.CONV. EN](http://download.weidmueller.com/asset/download/file/38237)
[MB DEVICE MANUF. EN](http://download.weidmueller.com/asset/download/file/38257) [FL MACHINE SAFETY EN](http://download.weidmueller.com/asset/download/file/38228) [FL 72H SAMPLE SER EN](http://download.weidmueller.com/asset/download/file/38294) [PO OMNIMATE EN](http://download.weidmueller.com/asset/download/file/38132) |
| ETIM 6.0 | EC002779 |
| ETIM 7.0 | EC002779 |
| ETIM 8.0 | EC002779 |
| ETIM 9.0 | EC002779 |
| ECLASS 9.0 | 27-18-27-90 |
| ECLASS 9.1 | 27-18-27-90 |
| ECLASS 10.0 | 27-18-27-92 |
| ECLASS 11.0 | 27-18-27-92 |
| ECLASS 12.0 | 27-18-27-92 |
| ECLASS 13.0 | 27-18-27-92 |
| ECLASS 14.0 | 27-18-27-92 |
| ROHS | Conform |
