Egenskaber
| Order No. | 2435110000 |
| Type | FAD S5135 SL42 A R |
| GTIN (EAN) | 4050118446975 |
| Qty. | 1 Styk |
| Depth | 23 mm |
| Depth (inches) | 0,906 inch |
| Height | 283 mm |
| Height (inches) | 11,142 inch |
| Width | 20 mm |
| Width (inches) | 0,787 inch |
| Net weight | 127 g |
| Storage temperature | -40...60 °C |
| Operating temperature | -25...50 °C |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 9d5ff7ee-74dc-449b-a1db-a29604b9b3e9 |
| Connection (field side) | SL 5.08 mm |
| Operating voltage | 250 V AC |
| Max. current per channel | 4 A |
| Total operating current | 32 A |
| Rated insulation voltage | < 250 V AC |
| Surge voltage category | II |
| Pollution severity level | 2 |
| Insulation test voltage AC | 1,2 kV |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.2435110000) |
| WSCAD Universe | [WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=2435110000&norm=0) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002584 |
| ETIM 7.0 | EC002584 |
| ETIM 8.0 | EC002584 |
| ETIM 9.0 | EC002584 |
| ECLASS 9.0 | 27-33-02-92 |
| ECLASS 9.1 | 27-24-22-92 |
| ECLASS 10.0 | 27-33-02-92 |
| ECLASS 11.0 | 27-33-02-92 |
| ECLASS 12.0 | 27-33-02-92 |
| ECLASS 13.0 | 27-33-02-92 |
| Approvals |  |
| ROHS | Conform |
