Properties
| Version | Field Power® terminal rail, Steel, galvanized, 230 mm, for plastic lid |
| Order No. | 2633520000 |
| Type | FP ENC DR07 230 3C P |
| GTIN (EAN) | 4050118664386 |
| Qty. | 5 items |
| Depth | 7.5 mm |
| Depth (inches) | 0.295 inch |
| Height | 35 mm |
| Height (inches) | 1.378 inch |
| Width | 230 mm |
| Width (inches) | 9.055 inch |
| Net weight | 83.4 g |
| Operating temperature | -40 °C...85 |
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 42d748fc-bbd3-41cb-951a-c952873e955b |
| Installation advice | Screws included |
| Insulating material | Steel |
| Material | Steel, galvanized |
| Colour | silver |
| Material | Steel, galvanized |
| Insulating material | Steel |
| Colour | silver |
| Type of mounting | Screw mounting |
| Mounting position, installation notice | for plastic lid |
| Installation advice | Screws included |
| Version | with slot |
| Approval/Certificate/Document of Conformity | [Manufacturer's Declaration FieldPower® Enclosure parts](https://mdcop.weidmueller.com/mediadelivery/asset/900_263559) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC001285 |
| ETIM 7.0 | EC001285 |
| ETIM 8.0 | EC001285 |
| ETIM 9.0 | EC001285 |
| ECLASS 9.0 | 27-40-06-02 |
| ECLASS 9.1 | 27-40-06-02 |
| ECLASS 10.0 | 27-40-06-02 |
| ECLASS 11.0 | 27-40-06-02 |
| ECLASS 12.0 | 27-40-06-02 |
| ECLASS 13.0 | 27-40-06-02 |
| ECLASS 14.0 | 27-40-06-02 |
| ROHS | Conform |
Accessories
ToolsScrewdriversBattery-operated torque screwdriverBits, bit holder and assortment of bits, 1/4" drive, E6.3Bits E6,3 - Torx®
ToolsScrewdriversBattery-operated torque screwdriverDMS PRO
Is accessory of
-
Item No.:2632940000Packaging unit:1 PC
FieldPower® enclosures, 196 mm, 284 mm, 155 mm, IP65, in closed state, Polycarbonate, glass-fibre reinforced polycarbonate, black, Transparent
-
Item No.:2632930000Packaging unit:1 PC
FieldPower® enclosures, 196 mm, 284 mm, 155 mm, IP65, in complete state, glass-fibre reinforced polycarbonate, black
-
Item No.:2632820000Packaging unit:1 PC
FieldPower® enclosures, 191 mm, 279 mm, 113 mm, IP65, in complete state, glass-fibre reinforced polycarbonate, black
-
Item No.:2632830000Packaging unit:1 PC
FieldPower® enclosures, 191 mm, 279 mm, 113 mm, IP65, in complete state, Polycarbonate, Transparent
Enclosure Systems and ComponentsFieldPower® IP 54...IP 65 enclosureEnclosuresetSize 3
Enclosure Systems and ComponentsFieldPower® IP 54...IP 65 enclosureEmpty lidSize 3
Individual parts
-
Item No.:1274150000Packaging unit:1 PC
Klippon EB (Essential Box), Mounting screw, Height: 13.3 mm, Width: 8.5 mm, Depth: 8.5 mm, Material: Steel, galvanized, galvanic zinc plated and passivated, silver
Enclosure Systems and ComponentsSteel enclosuresKlippon® EBAccessories - Klippon® EBMounting plates
