Properties
| Version | Flange FO, IP67, Version 4, coupling from SCRJ on 2*SC, Singlemode |
| Order No. | 1963420000 |
| Type | IE-BS-V04P-SCRJ2SC-SM-C |
| GTIN (EAN) | 4032248645510 |
| Qty. | 10 items |
| Depth | 48.3 mm |
| Depth (inches) | 1.902 inch |
| Height | 38 mm |
| Height (inches) | 1.496 inch |
| Width | 27 mm |
| Width (inches) | 1.063 inch |
| Net weight | 29.3 g |
| Operating temperature | -40 °C...70 °C |
| Connection 1 | SC |
| Connection 2 | SCRJ |
| Gender | female - female |
| Housing main material | PA UL 94 V0 |
| Housing style | V4 |
| Outlet direction | Straight |
| Protection degree | IP67 |
| Colour | Miscellaneous |
| Connection 1 | SC |
| Connection 2 | SCRJ |
| Description of article | Version 4, coupling from SCRJ on 2*SC |
| Fibre type | Singlemode |
| Housing main material | PA UL 94 V0 |
| Insertion loss | ≤ 0.5 dB |
| Plugging cycles | 500 |
| Protection degree | IP67 |
| Return loss (attenuation) | ≥ 40 dB |
| Connector standard |
IEC 61076-3-106 Var. 4
IEC 61754-4 IEC 61754-24 |
| Approval/Certificate/Document of Conformity |
[GOST Approval](https://mdcop.weidmueller.com/mediadelivery/asset/900_58423)
[PROFINET Manufacturer's Declaration](https://mdcop.weidmueller.com/mediadelivery/asset/900_67339) |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_261931) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1963420000) |
| WSCAD Universe | [WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=1963420000&norm=0) |
| User Documentation |
[MAN IE GUIDE DE](https://mdcop.weidmueller.com/mediadelivery/asset/900_40065)
[MAN IE GUIDE EN](https://mdcop.weidmueller.com/mediadelivery/asset/900_40066) [Designation key / Type key](https://mdcop.weidmueller.com/mediadelivery/asset/900_90842) [Manual](https://mdcop.weidmueller.com/mediadelivery/asset/900_96751) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) [PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) |
| ETIM 6.0 | EC001122 |
| ETIM 7.0 | EC001122 |
| ETIM 8.0 | EC001122 |
| ETIM 9.0 | EC001122 |
| ECLASS 9.0 | 19-17-01-22 |
| ECLASS 9.1 | 19-17-01-22 |
| ECLASS 10.0 | 19-17-01-22 |
| ECLASS 11.0 | 19-17-01-22 |
| ECLASS 12.0 | 19-17-01-22 |
| ECLASS 13.0 | 19-17-01-22 |
| ROHS | Conform |
