KCMA-18-200-1A-1.5VA-1
Product image
KCMA-18-200-1A-1.5VA-1
KCMA-18-200-1A-1.5VA-1
KCMA-18-200-1A-1.5VA-1

KCMA-18-200-1A-1.5VA-1

Corrente primaria: 200 A, Corrente secondaria max.: 1 A, Carico: 1.5 VA, Classe di precisione: 1, Convertitore di corrente con nucleo apribile

Product ID 2753020000
Gegevensblad downloaden Engineeringondersteuning Productdownloads
Verwante producten 68
Approvals Dati generali per l’ordinazione Dimensions and weights Temperatures Conformité environnementale du produit Dimensions of live conductors Electrical attributes General data Technical properties Insulation coordination Classifications

Approvals

ROHS
Conform

Dati generali per l’ordinazione

Version
Corrente primaria: 200 A, Corrente secondaria max.: 1 A, Carico: 1.5 VA, Classe di precisione: 1, Convertitore di corrente con nucleo apribile
Order No.
2753020000
Type
KCMA-18-200-1A-1.5VA-1
GTIN (EAN)
4050118896916
Qty.
1 items

Dimensions and weights

Depth
59 mm
Profondità (pollici)
2,323 inch
Height
80,1 mm
Height (inches)
3,154 inch
Width
49 mm
Width (inches)
1,929 inch
Net weight
345 g

Temperatures

Operating temperature
-5 °C...50 °C

Conformité environnementale du produit

RoHS Compliance Status
Conforme sans exemption
REACH SVHC
No SVHC above 0.1 wt%

Dimensions of live conductors

Type of conductor
Csak szigetelt vezető
Round conductor
18,5 mm
Installation location
Indoor use

Electrical attributes

Load
1,5 VA
Primary current
200 A
Secondary current
0...1 A
Tolerance class
1

General data

Manufacturer
MBS AG

Technical properties

Cable length
2,5 m
Nominal frequency
50 Hz
Protection degree
IP20

Insulation coordination

Tolerance class
1

Classifications

ETIM 8.0
EC002048
ETIM 9.0
EC002048
ETIM 10.0
EC002048
ECLASS 14.0
27-21-09-02
ECLASS 15.0
27-21-09-02
