KLIPPON BDX M20 BN

Klippon BDX (compensating elements), Compensating element, M 20, 10 mm, IP66, Brass, nickel-plated

Item No. 2519540000

Version	Klippon BDX (compensating elements), Compensating element, M 20, 10 mm, IP66, Brass, nickel-plated
Order No.	2519540000
Type	KLIPPON BDX M20 BN
GTIN (EAN)	4050118532067
Qty.	1 items

Operating temperature

-60 °C...200 °C

REACH SVHC

Lead 7439-92-1

Approval conditions	ATEX IECEX UL AEx Class Div. UL AEx Class Zone
Certificate no. cable gland (ATEX)	SIRA 09ATEX3321X or CML 19ATEX3347X
Certificate no. cable gland (CSA)	2310046 or E340660
Certificate no. cable gland (IECEx)	IECEx SIR 09.0132X or IECEx CML 19.0105X
Identification	Ex e IIC Gb Ex ta IIIC Da

AF size 1	27 mm
Air flow	0.25 l / 1 h
Explosion protection type	Improved safety Ex e
External thread	M 20
Filter	Bronze insert (90% copper, 10% tin)
Halogen	halogen-free
Head diameter	26.2 mm
Impact resistance	7 J ATEX version
Length of thread	10 mm
Material	Brass, nickel-plated
Note: protection class	- The venting element should be fitted on the bottom side of the enclosure, aligned vertically with the thread upwards, and at the lowest point to permit proper drainage. - The supplied assembly instructions must be read prior to installation and strictly adhered to. - The water flow rate was tested using a water-filled, empty enclosure (no pressure or heat-producing internal components). The water flow rate may vary due to operational parameters and environmental conditions.
O-Ring	Silicone
Operating temperature range, max.	200 °C
Operating temperature range, min.	-60 °C
Pitch of thread	1.5 mm
Protection class (UL)	Type 4
Protection degree	IP66
Protection degree with GWDR	IP66
Sealing	Silicone
Silicone	Yes
Standards	IEC 60079-0 IEC 60079-7 IEC 60079-31
Tightening torque	10 Nm
Torque for connecting adapter, max.	10 Nm
Torque for connecting adapter, min.	10 Nm
Torque for lock nut, max.	10 Nm
Torque for lock nut, min.	10 Nm

Engineering Data	[CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_72098)
Eplan Data Portal	[Eplan data](https://dataportal.eplan.com/part-details/WEI.2519540000)
CADENAS eCATALOG	[CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2519540000)
WSCAD Universe	[WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=2519540000&norm=0)
Catalogues	[Catalogues in PDF-format](LINK/Catalog.html)

ROHS

Conform
