Properties
| Version | Busbar (terminal), silver, Height: 15 mm, Depth: 2 mm, Copper |
| Order No. | 1313600000 |
| Type | NSCH 2M |
| GTIN (EAN) | 4008190052096 |
| Qty. | 2 |
| Depth | 2 mm |
| Depth (inches) | 0.079 inch |
| Height | 15 mm |
| Height (inches) | 0.591 inch |
| Width | 2,000 mm |
| Width (inches) | 78.74 inch |
| Net weight | 396.53 g |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Material | Copper |
| Surface finish | electropolished |
| Colour | silver |
| Installation advice | Direct mounting |
| Installation advice | Direct mounting |
| Surface finish | electropolished |
| Rated current | 24 A |
| Approval/Certificate/Document of Conformity |
[Attestation of Conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_80656)
[UKCA Attestation of conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_255566) [ATEX Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_80376) [IECEx Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_80377) [UKCA Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_255567) |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_70268) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1313600000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1313600000) |
| User Documentation | [StorageConditionsTerminalBlocks](https://mdcop.weidmueller.com/mediadelivery/asset/900_87149) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002848 |
| ETIM 7.0 | EC002848 |
| ETIM 8.0 | EC002848 |
| ETIM 9.0 | EC002848 |
| ECLASS 9.0 | 27-14-11-92 |
| ECLASS 9.1 | 27-14-11-92 |
| ECLASS 10.0 | 27-14-11-92 |
| ECLASS 11.0 | 27-14-11-92 |
| ECLASS 12.0 | 27-14-11-92 |
| ECLASS 13.0 | 27-14-11-92 |
| ECLASS 14.0 | 27-14-11-92 |
| ROHS | Conform |
Accessories
-
Item No.:0296700000Packaging unit:100 PC
Mounting screw (Terminal), 5.00 mm, Steel, Depth: 8.5 mm, Width: 8.5 mm, Height: 8.5 mm
-
Item No.:0280100000Packaging unit:100 PC
Fastening element (Terminal), silver, Height: 12.5 mm, Width: 10 mm, Steel, 180 °C
-
Item No.:0299860000Packaging unit:20 PC
Busbar support, beige, 100 °C, Width: 26 mm, V-2, Polyamide 66, when screwed in
